Sony HCD-VX5A - Page 78

– 106 –
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
R482 1-260-089-11 CARBON 150 5% 1/2W
R483 1-260-089-11 CARBON 150 5% 1/2W
R484 1-260-089-11 CARBON 150 5% 1/2W
R501 1-249-413-11 CARBON 470 5% 1/4W
R502 1-249-425-11 CARBON 4.7K 5% 1/4W
R503 1-249-437-11 CARBON 47K 5% 1/4W
R504 1-249-437-11 CARBON 47K 5% 1/4W
R505 1-249-429-11 CARBON 10K 5% 1/4W
R508 1-249-417-11 CARBON 1K 5% 1/4W
R509 1-249-441-11 CARBON 100K 5% 1/4W
R521 1-249-425-11 CARBON 4.7K 5% 1/4W
R522 1-249-407-11 CARBON 150 5% 1/4W
(VX5A/VX5AJ)
R522 1-249-411-11 CARBON 330 5% 1/4W
(VX7A)
R523 1-249-425-11 CARBON 4.7K 5% 1/4W
R524 1-249-407-11 CARBON 150 5% 1/4W
(E, MY, SP, IA, HK, TW)
R524 1-249-415-11 CARBON 680 5% 1/4W
(TH)
R524 1-249-419-11 CARBON 1.5K 5% 1/4W
(JE)
R524 1-249-425-11 CARBON 4.7K 5% 1/4W
(EA)
R527 1-249-429-11 CARBON 10K 5% 1/4W
R536 1-249-429-11 CARBON 10K 5% 1/4W
R550 1-247-843-11 CARBON 3.3K 5% 1/4W
R551 1-249-429-11 CARBON 10K 5% 1/4W
R567 1-247-807-31 CARBON 100 5% 1/4W
R568 1-249-429-11 CARBON 10K 5% 1/4W
R569 1-249-429-11 CARBON 10K 5% 1/4W
R570 1-249-429-11 CARBON 10K 5% 1/4W
R571 1-249-429-11 CARBON 10K 5% 1/4W
R577 1-249-429-11 CARBON 10K 5% 1/4W
R610 1-247-891-00 CARBON 330K 5% 1/4W
R617 1-249-429-11 CARBON 10K 5% 1/4W
R618 1-247-807-31 CARBON 100 5% 1/4W
R622 1-249-425-11 CARBON 4.7K 5% 1/4W
R626 1-247-807-31 CARBON 100 5% 1/4W
R627 1-247-807-31 CARBON 100 5% 1/4W
R629 1-247-807-31 CARBON 100 5% 1/4W
R630 1-247-807-31 CARBON 100 5% 1/4W
R636 1-247-807-31 CARBON 100 5% 1/4W
R639 1-247-807-31 CARBON 100 5% 1/4W
R640 1-247-807-31 CARBON 100 5% 1/4W
R642 1-247-807-31 CARBON 100 5% 1/4W
R643 1-247-807-31 CARBON 100 5% 1/4W
R649 1-247-807-31 CARBON 100 5% 1/4W
R650 1-247-807-31 CARBON 100 5% 1/4W
R651 1-247-807-31 CARBON 100 5% 1/4W
R652 1-247-807-31 CARBON 100 5% 1/4W
R653 1-247-807-31 CARBON 100 5% 1/4W
R654 1-247-807-31 CARBON 100 5% 1/4W
R655 1-247-807-31 CARBON 100 5% 1/4W
R659 1-247-807-31 CARBON 100 5% 1/4W
R660 1-247-807-31 CARBON 100 5% 1/4W
R661 1-247-807-31 CARBON 100 5% 1/4W
R663 1-247-807-31 CARBON 100 5% 1/4W
R665 1-247-807-31 CARBON 100 5% 1/4W
R666 1-247-807-31 CARBON 100 5% 1/4W
R667 1-247-807-31 CARBON 100 5% 1/4W
R668 1-247-807-31 CARBON 100 5% 1/4W
R669 1-247-807-31 CARBON 100 5% 1/4W
R670 1-247-807-31 CARBON 100 5% 1/4W
R671 1-247-807-31 CARBON 100 5% 1/4W
R686 1-247-807-31 CARBON 100 5% 1/4W
R687 1-247-807-31 CARBON 100 5% 1/4W
R688 1-247-807-31 CARBON 100 5% 1/4W
R689 1-247-807-31 CARBON 100 5% 1/4W
R690 1-247-807-31 CARBON 100 5% 1/4W
R691 1-247-807-31 CARBON 100 5% 1/4W
R801 1-249-417-11 CARBON 1K 5% 1/4W
R802 1-249-438-11 CARBON 56K 5% 1/4W
R803 1-247-822-11 CARBON 430 5% 1/4W
(VX5AJ/VX7A)
R803 1-249-413-11 CARBON 470 5% 1/4W
(VX5A)
R804 1-249-438-11 CARBON 56K 5% 1/4W
R805 1-249-417-11 CARBON 1K 5% 1/4W
R806 1-249-431-11 CARBON 15K 5% 1/4W
R807 1-249-441-11 CARBON 100K 5% 1/4W
! R808 1-220-893-11 METAL 0.22 10% 5W F
R809 1-260-076-11 CARBON 10 5% 1/2W
R810 1-260-105-11 CARBON 3.3K 5% 1/2W
! R811 1-212-881-11 FUSIBLE 100 5% 1/4W F
! R812 1-202-972-61 FUSIBLE 1 5% 1/4W F
R813 1-249-435-11 CARBON 33K 5% 1/4W
R814 1-249-421-11 CARBON 2.2K 5% 1/4W
R815 1-249-433-11 CARBON 22K 5% 1/4W
R816 1-249-429-11 CARBON 10K 5% 1/4W
R817 1-249-421-11 CARBON 2.2K 5% 1/4W
R818 1-249-435-11 CARBON 33K 5% 1/4W
R819 1-249-439-11 CARBON 68K 5% 1/4W
R831 1-249-441-11 CARBON 100K 5% 1/4W
R832 1-249-441-11 CARBON 100K 5% 1/4W
R833 1-249-436-11 CARBON 39K 5% 1/4W
(VX5AJ/VX7A)
R833 1-249-437-11 CARBON 47K 5% 1/4W
(VX5A)
R842 1-249-441-11 CARBON 100K 5% 1/4W
R851 1-249-417-11 CARBON 1K 5% 1/4W
R852 1-249-438-11 CARBON 56K 5% 1/4W
R853 1-247-822-11 CARBON 430 5% 1/4W
(VX5AJ/VX7A)
R853 1-249-413-11 CARBON 470 5% 1/4W
(VX5A)
R854 1-249-438-11 CARBON 56K 5% 1/4W
R855 1-249-417-11 CARBON 1K 5% 1/4W
R856 1-249-431-11 CARBON 15K 5% 1/4W
R857 1-249-441-11 CARBON 100K 5% 1/4W
! R858 1-220-893-11 METAL 0.22 10% 5W F
R859 1-260-076-11 CARBON 10 5% 1/2W
R860 1-260-105-11 CARBON 3.3K 5% 1/2W
! R861 1-212-881-11 FUSIBLE 100 5% 1/4W F
R881 1-249-435-11 CARBON 33K 5% 1/4W
R882 1-249-435-11 CARBON 33K 5% 1/4W
R892 1-249-441-11 CARBON 100K 5% 1/4W
MAIN
The components identified by mark ! or dotted
line with mark ! are critical for safety.
Replace only with part number specified.
