Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
R901 1-247-843-11 CARBON 3.3K 5% 1/4W
R902 1-249-415-11 CARBON 680 5% 1/4W
R903 1-249-419-11 CARBON 1.5K 5% 1/4W
R904 1-249-414-11 CARBON 560 5% 1/4W
R905 1-249-425-11 CARBON 4.7K 5% 1/4W
R906 1-247-843-11 CARBON 3.3K 5% 1/4W
R907 1-249-415-11 CARBON 680 5% 1/4W
R908 1-249-429-11 CARBON 10K 5% 1/4W
R909 1-249-430-11 CARBON 12K 5% 1/4W
R911 1-249-409-11 CARBON 220 5% 1/4W
R916 1-249-421-11 CARBON 2.2K 5% 1/4W
R917 1-260-087-81 CARBON 100 5% 1/2W
R918 1-249-421-11 CARBON 2.2K 5% 1/4W
R919 1-249-409-11 CARBON 220 5% 1/4W
R920 1-249-383-11 CARBON 1.5 5% 1/6W
R921 1-249-383-11 CARBON 1.5 5% 1/6W
R931 1-249-429-11 CARBON 10K 5% 1/4W
< VARIABLE RESISTOR >
RV301 1-238-600-11 RES, ADJ, CARBON 10K
RV351 1-238-600-11 RES, ADJ, CARBON 10K
< RELAY >
RY401 1-755-168-11 RELAY
< THERMISTOR >
TH831 1-807-796-11 THERMISTOR
< TERMINAL >
TM401 1-537-240-31 TERMINAL BOARD (CHECKER PIN) (SPEAKER)
TM402 1-537-240-31 TERMINAL BOARD (CHECKER PIN)
(SURROUND SPEAKER) (VX7A)
< VIBRATOR >
X601 1-567-098-41 VIBRATOR, CRYSTAL (32.768kHz)
X613 1-781-107-21 VIBRATOR, SERAMIC (16MHz)
**************************************************************
* 1-658-578-11 MOTOR (SLIDE) BOARD
*******************
< CAPACITOR >
C801 1-162-306-11 CERAMIC 0.01uF 30% 16V
C804 1-162-306-11 CERAMIC 0.01uF 30% 16V
C805 1-126-964-11 ELECT 10uF 20% 50V
< CONNECTOR >
* CN801 1-568-947-11 PIN, CONNECTOR 9P
< DIODE >
D801 8-719-921-48 DIODE MTZJ-T-72-5.6C
D804 8-719-911-19 DIODE 1N4148M-TP
D805 8-719-911-19 DIODE 1N4148M-TP
< IC >
IC801 8-759-274-09 IC BA6286N
< RESISTOR >
R801 1-249-401-11 CARBON 47 5% 1/4W
< SWITCH >
S801 1-762-527-11 SWITCH, ROTARY (OPEN/CLOSE DET)
**************************************************************
* 1-658-577-11 MOTOR (TURN) BOARD
*******************
< CAPACITOR >
C701 1-162-306-11 CERAMIC 0.01uF 30% 16V
C702 1-126-964-11 ELECT 10uF 20% 50V
C705 1-162-306-11 CERAMIC 0.01uF 30% 16V
< CONNECTOR >
CN703 1-785-550-11 CONNECTOR, FFC/FPC 8P
CN704 1-506-469-11 PIN, CONNECTOR 4P
< DIODE >
D701 8-719-983-66 DIODE MTZJ-T-72-3.6B
< IC >
IC701 8-759-633-65 IC M54641L
< RESISTOR >
R706 1-249-411-11 CARBON 330 5% 1/4W
R707 1-249-401-11 CARBON 47 5% 1/4W
**************************************************************
A-4419-160-A PANEL BOARD, COMPLETE
(VX7A: E, EA, MY, SP)
A-4419-152-A PANEL BOARD, COMPLETE
(VX5A: E, EA, MY, SP, HK, TW)
A-4426-093-A PANEL BOARD, COMPLETE (VX5AJ)
A-4426-139-A PANEL BOARD, COMPLETE (VX5A: IA)
A-4426-147-A PANEL BOARD, COMPLETE (VX7A: IA)
A-4426-156-A PANEL BOARD, COMPLETE (VX5A: TH)
A-4426-164-A PANEL BOARD, COMPLETE (VX7A: TH)
**********************
* 4-214-439-11 HOLDER, FL TUBE
* 4-949-935-81 CUSHION (FL)
< CAPACITOR >
C601 1-124-589-11 ELECT 47uF 20% 16V
C602 1-126-163-11 ELECT 4.7uF 20% 50V
C603 1-162-306-11 CERAMIC 0.01uF 30% 16V
C604 1-162-294-31 CERAMIC 0.001uF 10% 50V
C606 1-126-160-11 ELECT 1uF 20% 50V
C607 1-126-160-11 ELECT 1uF 20% 50V
C610 1-124-589-11 ELECT 47uF 20% 16V
C611 1-162-306-11 CERAMIC 0.01uF 30% 16V
C612 1-162-306-11 CERAMIC 0.01uF 30% 16V
C614 1-162-306-11 CERAMIC 0.01uF 30% 16V
C615 1-162-306-11 CERAMIC 0.01uF 30% 16V
C616 1-126-157-11 ELECT 10uF 20% 16V
C617 1-162-303-11 CERAMIC 0.0033uF 30% 16V
MAIN MOTOR (SLIDE) MOTOR (TURN) PANEL
