– 86 –
Pin Name
I/O
Function
Pin No.
91 PGIO0 I/O Not used
92 PGIO8 I/O Not used
93 PGIO2/VSYNC/CSYNC O Vertical synchronized signal of video signal
94 AVDD PLL – +3.3V Power supply
95 NC – Not used
96 NC – Not used
97 NC – Not used
98 AGND PLL – Ground
99 VSS – Ground
100 NC – Not used
101 PGIO3/HSYNC I/O Not used
102 VDD3 – +3.3V Power supply
103 PGIO1/VCK-OUT I/O Not used
104 VSS – Ground
105 GCK I Not used
106 VCK-IN I Main clock for video signal processer
107 GCKOUT/DA-EMP O Not used
108 DA-LRCK O Digital Audio Left or Right channel selection clock
109 VDDMAX-OUT O Fix the maxium output voltage certain output pins (Connected to +5V)
110 DA-DATA O Digital Audio data
111 DA-BCK O Digital Audio bit clock
112 HD-OUT O Serial Data output from CL680 to the host MPU
113 HRDY O Ready signal CL680 is ready for communication to the host MPU
114 HINT O Request signal for interrupting the host MPU
115 CDG-SCK I/O Not used
116 VSS – Ground
117 HCK I Host clock : referance signal for the host bus interface
118 VDD3 – +3.3V Power supply
119 HD-IN I Serial Data output ftom the host MPU to CL680
120 VDD3 – +3.3V Power supply
121 HSEL I Select data or address of the host MPU
122 CDG-SDATA I Ground (Not used)
123 CDG-VFSY I Ground (Not used)
124 CDG-SOS1 I Ground (Not used)
125 NC – Not used
126 NC – Not used
127 NC – Not used
128 NC – Not used
