– 103 –
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
MAIN
< FERRITE BEAD >
FB391 1-412-493-21 INDUCTOR
FB392 1-412-493-21 INDUCTOR
< IC >
IC101 8-759-571-54 IC M62493FP
IC181 8-759-634-51 IC M5218AP
IC301 8-759-495-26 IC HA12215
IC381 8-749-923-04 IC TOTX178
IC501 8-759-588-91 IC M30622MA-A09FP
IC502 8-759-635-63 IC M51943BSL
IC801 8-749-015-37 IC STK411-240E
IC901 8-759-604-86 IC M5F7807L
IC902 8-759-231-53 IC TA7805S
IC903 8-759-088-08 IC UPC7812AHF
IC904 8-759-231-53 IC TA7805S
< JACK >
J101 1-774-411-11 JACK, PIN 6P (VIDEO AUDIO IN, MD IN/OUT)
J191 1-774-785-11 JACK, PIN 1P (SUPER WOOFER)
< COIL >
L381 1-410-521-11 INDUCTOR 100uH
L392 1-410-521-11 INDUCTOR 100uH
L501 1-410-509-11 INDUCTOR 10uH
< TRANSISTOR >
Q111 8-729-119-78 TRANSISTOR 2SC403SP-51
Q112 8-729-119-78 TRANSISTOR 2SC403SP-51
Q113 8-729-141-30 TRANSISTOR 2SC3623A-LK
Q161 8-729-119-78 TRANSISTOR 2SC403SP-51
Q162 8-729-119-78 TRANSISTOR 2SC403SP-51
Q163 8-729-141-30 TRANSISTOR 2SC3623A-LK
Q181 8-729-141-30 TRANSISTOR 2SC3623A-LK
Q191 8-729-141-30 TRANSISTOR 2SC3623A-LK
Q192 8-729-900-63 TRANSISTOR DTA124ES
Q201 8-729-900-36 TRANSISTOR DTC124ES
Q251 8-729-900-36 TRANSISTOR DTC124ES
Q331 8-729-118-00 TRANSISTOR 2SB1116-L
Q332 8-729-900-80 TRANSISTOR DTC114ES
Q333 8-729-118-00 TRANSISTOR 2SB1116-L
Q334 8-729-900-80 TRANSISTOR DTC114ES
Q335 8-729-900-80 TRANSISTOR DTC114ES
Q336 8-729-116-59 TRANSISTOR 2SB1068TP
Q337 8-729-045-21 TRANSISTOR 2SD1513TP-LK
Q338 8-729-422-57 TRANSISTOR UN4111
Q339 8-729-900-80 TRANSISTOR DTC114ES
Q340 8-729-116-59 TRANSISTOR 2SB1068TP
Q341 8-729-045-21 TRANSISTOR 2SD1513TP-LK
Q342 8-729-422-57 TRANSISTOR UN4111
Q343 8-729-900-80 TRANSISTOR DTC114ES
Q401 8-729-119-77 TRANSISTOR 2SA1175-FEK
Q402 8-729-111-29 TRANSISTOR 2SD1616A-K
Q411 8-729-141-30 TRANSISTOR 2SC3623A-LK
Q412 8-729-900-63 TRANSISTOR DTA124ES
Q431 8-729-140-84 TRANSISTOR 2SC1841-PAFAEA
Q432 8-729-140-82 TRANSISTOR 2SA988-PAFAEA
Q433 8-729-140-84 TRANSISTOR 2SC1841-PAFAEA
Q434 8-729-140-84 TRANSISTOR 2SC1841-PAFAEA
Q435 8-729-900-36 TRANSISTOR DTC124ES
Q436 8-729-119-77 TRANSISTOR 2SA1175-FEK
Q437 8-729-119-79 TRANSISTOR 2SC2785-FEK
Q439 8-729-119-79 TRANSISTOR 2SC2785-FEK
Q471 8-729-141-30 TRANSISTOR 2SC3623A-LK
Q501 8-729-119-78 TRANSISTOR 2SC403SP-51
Q508 8-729-900-63 TRANSISTOR DTA124ES
Q509 8-729-900-63 TRANSISTOR DTA124ES
Q801 8-729-140-84 TRANSISTOR 2SC1841-PAFAEA
Q803 8-729-140-82 TRANSISTOR 2SA988-PAFAEA
Q804 8-729-140-84 TRANSISTOR 2SC1841-PAFAEA
Q831 8-729-140-84 TRANSISTOR 2SC1841-PAFAEA
Q832 8-729-119-79 TRANSISTOR 2SC2785-FEK
Q851 8-729-140-84 TRANSISTOR 2SC1841-PAFAEA
Q881 8-729-140-84 TRANSISTOR 2SC1841-PAFAEA
Q901 8-729-209-15 TRANSISTOR 2SD2012
Q902 8-729-119-78 TRANSISTOR 2SC403SP-51
Q903 8-729-900-36 TRANSISTOR DTC124ES
Q904 8-729-900-36 TRANSISTOR DTC124ES
Q905 8-729-040-20 TRANSISTOR RT1P137L-TP
Q907 8-729-141-83 TRANSISTOR 2SB1094-LK
Q908 8-729-900-36 TRANSISTOR DTC124ES
Q909 8-729-026-68 TRANSISTOR 2SD2525(TP)
Q911 8-729-141-83 TRANSISTOR 2SB1094-LK
Q912 8-729-900-36 TRANSISTOR DTC124ES
Q913 8-729-119-78 TRANSISTOR 2SC403SP-51
Q914 8-729-119-77 TRANSISTOR 2SA1175-FEK
Q923 8-729-900-36 TRANSISTOR DTC124ES
Q951 8-729-141-83 TRANSISTOR 2SB1094-LK
Q952 8-729-119-77 TRANSISTOR 2SA1175-FEK
< RESISTOR >
R101 1-249-417-11 CARBON 1K 5% 1/4W F
R102 1-249-417-11 CARBON 1K 5% 1/4W F
R103 1-249-417-11 CARBON 1K 5% 1/4W F
R111 1-249-429-11 CARBON 10K 5% 1/4W
R112 1-247-895-00 CARBON 470K 5% 1/4W
R113 1-247-894-11 CARBON 430K 5% 1/4W
R114 1-249-415-11 CARBON 680 5% 1/4W F
R115 1-249-433-11 CARBON 22K 5% 1/4W
R116 1-247-887-00 CARBON 220K 5% 1/4W
R117 1-249-429-11 CARBON 10K 5% 1/4W
R118 1-249-437-11 CARBON 47K 5% 1/4W
R119 1-249-421-11 CARBON 2.2K 5% 1/4W F
R120 1-249-441-11 CARBON 100K 5% 1/4W
R121 1-249-429-11 CARBON 10K 5% 1/4W
R124 1-249-433-11 CARBON 22K 5% 1/4W F
R125 1-247-843-11 CARBON 3.3K 5% 1/4W
R126 1-249-421-11 CARBON 2.2K 5% 1/4W F
R130 1-249-433-11 CARBON 22K 5% 1/4W
R131 1-247-807-31 CARBON 100 5% 1/4W
R132 1-247-807-31 CARBON 100 5% 1/4W
R133 1-247-807-31 CARBON 100 5% 1/4W
