– 47 –
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
––––––– ––––––– –––––––––– ––––––– ––––––– ––––––– –––––––––– ––––––
R105 1-216-093-00 METAL CHIP 68K 5% 1/10W
R106 1-216-093-00 METAL CHIP 68K 5% 1/10W
R107 1-216-093-00 METAL CHIP 68K 5% 1/10W
R108 1-216-093-00 METAL CHIP 68K 5% 1/10W
R109 1-216-097-91 METAL GLAZE 100K 5% 1/10W
R112 1-216-083-00 METAL CHIP 27K 5% 1/10W
R113 1-216-083-00 METAL CHIP 27K 5% 1/10W
R114 1-216-101-00 METAL CHIP 150K 5% 1/10W
R115 1-216-101-00 METAL CHIP 150K 5% 1/10W
R116 1-216-061-00 METAL CHIP 3.3K 5% 1/10W
R117 1-216-069-00 METAL CHIP 6.8K 5% 1/10W
R118 1-216-049-91 METAL GLAZE 1K 5% 1/10W
R119 1-216-089-91 METAL GLAZE 47K 5% 1/10W
R120 1-216-089-91 METAL GLAZE 47K 5% 1/10W
R121 1-216-114-00 METAL GLAZE 510K 5% 1/10W
R122 1-216-097-91 METAL GLAZE 100K 5% 1/10W
R123 1-216-099-00 METAL CHIP 120K 5% 1/10W
R124 1-216-091-00 METAL CHIP 56K 5% 1/10W
R125 1-216-069-00 METAL CHIP 6.8K 5% 1/10W
R126 1-216-063-91 METAL GLAZE 3.9K 5% 1/10W
R127 1-216-089-91 METAL GLAZE 47K 5% 1/10W
R128 1-216-105-91 METAL GLAZE 220K 5% 1/10W
R129 1-216-049-91 METAL GLAZE 1K 5% 1/10W
R130 1-216-079-00 METAL CHIP 18K 5% 1/10W
R131 1-216-079-00 METAL CHIP 18K 5% 1/10W
R132 1-216-061-00 METAL CHIP 3.3K 5% 1/10W
R133 1-216-061-00 METAL CHIP 3.3K 5% 1/10W
R134 1-216-065-00 METAL CHIP 4.7K 5% 1/10W
R135 1-216-065-00 METAL CHIP 4.7K 5% 1/10W
R136 1-216-073-00 METAL CHIP 10K 5% 1/10W
R137 1-216-065-00 METAL CHIP 4.7K 5% 1/10W
R138 1-216-049-91 METAL GLAZE 1K 5% 1/10W
R139 1-216-033-00 METAL CHIP 220 5% 1/10W
R140 1-216-081-00 METAL CHIP 22K 5% 1/10W
R141 1-216-061-00 METAL CHIP 3.3K 5% 1/10W
R142 1-216-061-00 METAL CHIP 3.3K 5% 1/10W
R143 1-216-121-91 METAL GLAZE 1M 5% 1/10W
R144 1-216-073-00 METAL CHIP 10K 5% 1/10W
R145 1-216-097-91 METAL GLAZE 100K 5% 1/10W
R146 1-216-097-91 METAL GLAZE 100K 5% 1/10W
R147 1-216-049-91 METAL GLAZE 1K 5% 1/10W
R148 1-216-049-91 METAL GLAZE 1K 5% 1/10W
R149 1-216-049-91 METAL GLAZE 1K 5% 1/10W
R150 1-216-037-00 METAL CHIP 330 5% 1/10W
R151 1-216-037-00 METAL CHIP 330 5% 1/10W
R152 1-216-037-00 METAL CHIP 330 5% 1/10W
R153 1-216-082-00 METAL GLAZE 24K 5% 1/10W
R154 1-216-065-00 METAL CHIP 4.7K 5% 1/10W
R156 1-216-085-00 METAL CHIP 33K 5% 1/10W
R157 1-216-069-00 METAL CHIP 6.8K 5% 1/10W
R158 1-216-001-00 METAL CHIP 10 5% 1/10W
< VARIABLE RESISTOR >
RV101 1-241-396-11 RES, ADJ, METAL GLAZE 22K (FOCUS BIAS)
RV102 1-241-396-11 RES, ADJ, METAL GLAZE 22K (FOCUS GAIN)
RV103 1-241-396-11 RES, ADJ, METAL GLAZE 22K(TRACKING GAIN)
< SWITCH >
S101 1-572-085-11 SWITCH, LEAF (LIMIT SW)
< VIBRATOR >
X101 1-579-280-11 VIBRATOR, CRYSTAL (16.9344MHz)
************************************************************
* 1-658-767-11 CD SWITCH BOARD
****************
< CONNECTOR >
CN255 1-774-341-11 PLUG, CONNECTOR (PC BOARD) 12P
< DIODE >
D270 8-719-052-21 LED SEL58420C-TP (DISC 1)
D271 8-719-052-21 LED SEL58420C-TP (DISC 2)
D272 8-719-052-21 LED SEL58420C-TP (DISC 3)
D273 8-719-052-43 LED SML59420C-TP4 ( )
D274 8-719-052-21 LED SEL58420C-TP (DISC 1)
D275 8-719-052-21 LED SEL58420C-TP (DISC 2)
D276 8-719-052-21 LED SEL58420C-TP (DISC 3)
< TRANSISTOR >
Q270 8-729-119-76 TRANSISTOR 2SA1175-HFE
Q271 8-729-119-76 TRANSISTOR 2SA1175-HFE
Q272 8-729-119-76 TRANSISTOR 2SA1175-HFE
Q273 8-729-119-76 TRANSISTOR 2SA1175-HFE
Q274 8-729-119-76 TRANSISTOR 2SA1175-HFE
Q275 8-729-119-76 TRANSISTOR 2SA1175-HFE
Q276 8-729-119-76 TRANSISTOR 2SA1175-HFE
Q277 8-729-119-76 TRANSISTOR 2SA1175-HFE
< RESISTOR >
R270 1-247-807-31 CARBON 100 5% 1/4W
R271 1-249-406-11 CARBON 120 5% 1/4W
R272 1-249-406-11 CARBON 120 5% 1/4W
R273 1-249-407-11 CARBON 150 5% 1/4W
R274 1-249-408-11 CARBON 180 5% 1/4W
R275 1-249-409-11 CARBON 220 5% 1/4W
R276 1-249-429-11 CARBON 10K 5% 1/4W
R277 1-249-429-11 CARBON 10K 5% 1/4W
R278 1-249-429-11 CARBON 10K 5% 1/4W
R279 1-249-429-11 CARBON 10K 5% 1/4W
R280 1-247-807-31 CARBON 100 5% 1/4W
R282 1-249-429-11 CARBON 10K 5% 1/4W
R283 1-249-429-11 CARBON 10K 5% 1/4W
CD SWITCH
BD
