– 48 –
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
––––––– ––––––– –––––––––– ––––––– ––––––– ––––––– –––––––––– ––––––
R284 1-249-429-11 CARBON 10K 5% 1/4W
R285 1-249-429-11 CARBON 10K 5% 1/4W
R286 1-247-807-31 CARBON 100 5% 1/4W
R288 1-249-429-11 CARBON 10K 5% 1/4W
R289 1-249-429-11 CARBON 10K 5% 1/4W
R290 1-249-429-11 CARBON 10K 5% 1/4W
R291 1-249-429-11 CARBON 10K 5% 1/4W
R292 1-247-807-31 CARBON 100 5% 1/4W
R294 1-249-429-11 CARBON 10K 5% 1/4W
R295 1-249-429-11 CARBON 10K 5% 1/4W
R296 1-249-429-11 CARBON 10K 5% 1/4W
R297 1-249-429-11 CARBON 10K 5% 1/4W
R298 1-249-409-11 CARBON 220 5% 1/4W
< SWITCH >
S270 1-554-303-21 SWITCH, TACTILE (DISK SKIP)
S271 1-554-303-21 SWITCH, TACTILE (DISC 1)
S272 1-554-303-21 SWITCH, TACTILE (DISC 2)
S273 1-554-303-21 SWITCH, TACTILE (DISC 3)
S274 1-554-303-21 SWITCH, TACTILE (OPEN/CLOSE)
S275 1-554-303-21 SWITCH, TACTILE (π )
S276 1-554-303-21 SWITCH, TACTILE (^)
************************************************************
* 1-658-770-11 CONNECTION BOARD
*****************
< CONNECTOR >
* CN252 1-569-306-11 SOCKET, CONNECTOR (L TYRE) 15P
CN253 1-774-335-11 SOCKET, CONNECTOR(PC BOARD)12P
CN254 1-770-391-11 PIN, CONNECTOR (PC BOARD) 7P
< DIODE >
D201 8-719-987-63 DIODE 1N4148M
D202 8-719-987-63 DIODE 1N4148M
D209 8-719-200-82 DIODE 11ES2
************************************************************
* 1-660-021-11 CONNECTOR BOARD
*****************
< CONNECTOR >
* CN1701 1-568-946-11 PIN, CONNECTOR 8P
CN1702 1-750-413-11 CONNECTOR, FFC/FPC 8P
< TRANSISTOR >
Q1701 8-729-900-80 TRANSISTOR DTC114ES
< RESISTOR >
R1703 1-249-435-11 CARBON 33K 5% 1/4W
R1704 1-249-429-11 CARBON 10K 5% 1/4W
R1705 1-249-417-11 CARBON 1K 5% 1/4W
************************************************************
* 1-650-669-11 LEAF SWITCH BOARD
******************
< CONNECTOR >
* CN1001 1-568-854-11 SOCKET, CONNECTOR 11P
< TRANSISTOR >
Q1001 8-749-010-90 TRANSISTOR NJL5165KA-H2
Q1002 8-749-010-90 TRANSISTOR NJL5165KA-H2
< RESISTOR >
R1001 1-249-412-11 CARBON 390 5% 1/4W
R1002 1-249-412-11 CARBON 390 5% 1/4W
R1003 1-249-414-11 CARBON 560 5% 1/4W
R1004 1-247-834-11 CARBON 1.3K 5% 1/4W
R1005 1-247-818-11 CARBON 300 5% 1/4W
< SWITCH >
S1001 1-692-832-11 SWITCH, PUSH (1 KEY)(A PLAY)
S1002 1-692-832-11 SWITCH, PUSH (1 KEY)(B PLAY)
S1004 1-571-281-21 SWITCH, LEAF (A HALF)
S1005 1-571-281-21 SWITCH, LEAF (A CrO2)
S1006 1-572-248-11 SWITCH, LEAF (REC A)
S1007 1-572-248-11 SWITCH, LEAF (B HALF)
S1008 1-571-281-21 SWITCH, LEAF (B CrO2)
S1009 1-571-281-21 SWITCH, LEAF (REC B)
************************************************************
* 1-659-382-11 LED BOARD
**********
< DIODE >
D301 8-719-302-07 LED SEL1810A
D302 8-719-302-07 LED SEL1810A
D303 8-719-302-07 LED SEL1810A
D304 8-719-302-07 LED SEL1810A
< RESISTOR >
R301 1-249-401-11 CARBON 47 5% 1/4W
R302 1-249-401-11 CARBON 47 5% 1/4W
************************************************************
* 1-658-772-11 LIGHT OUT BOARD
***************
< CONNECTOR >
CN107 1-770-011-41 CONNECTOR, BOARD TO BOARD 4P
< IC >
IC107 8-749-921-12 IC GP1F32T (CD) (OPTICAL DIGITAL OUT)
************************************************************
LIGHT OUT
LED
LEAF SWITCH
CONNECTOR
CONNECTION
CD SWITCH
To Next Page
