– 52 –
C1702 1-126-964-11 ELECT 10uF 20% 50V
C1705 1-162-306-11 CERAMIC 0.01uF 30% 16V
< CONNECTOR >
CN1703 1-750-413-11 CONNECTOR, FFC/FPC 8P
CN1704 1-506-469-11 PIN, CONNECTOR 4P
< DIODE >
D1701 8-719-109-81 DIODE RD4.7ESB2
< IC >
IC1701 8-759-633-65 IC M54641L
************************************************************
* 1-660-024-11 SENSOR BOARD
*************
< IC >
IC1702 8-749-924-18 IC RPI-1391
IC1703 8-749-924-30 IC GP2S28
< RESISTOR >
R1701 1-249-416-11 CARBON 820 5% 1/4W
R1702 1-249-407-11 CARBON 150 5% 1/4W
************************************************************
* 1-658-768-11 TC (A) SWITCH BOARD
*******************
< CONNECTOR >
CN256 1-770-400-11 HOUSING, CONNECTOR(PC BOARD)7P
< DIODE >
D260 8-719-046-43 LED SEL5421E-TP15 (·)
D261 8-719-046-43 LED SEL5421E-TP15 (ª)
< LEAD, JUMPER >
* JW301 1-535-730-21 LEAD, JUMPER (OFC)
* JW302 1-535-730-21 LEAD, JUMPER (OFC)
* JW303 1-535-730-21 LEAD, JUMPER (OFC)
* JW304 1-535-730-21 LEAD, JUMPER (OFC)
< RESISTOR >
R260 1-247-807-31 CARBON 100 5% 1/4W
R261 1-249-406-11 CARBON 120 5% 1/4W
R262 1-249-406-11 CARBON 120 5% 1/4W
R263 1-249-407-11 CARBON 150 5% 1/4W
< SWITCH >
S260 1-554-303-21 SWITCH, TACTILE (·)
S261 1-554-303-21 SWITCH, TACTILE (ª)
S262 1-554-303-21 SWITCH, TACTILE (p)
S263 1-554-303-21 SWITCH, TACTILE ())
S264 1-554-303-21 SWITCH, TACTILE (0)
************************************************************
* 1-658-769-11 TC (B) SWITCH BOARD
*******************
< CONNECTOR >
CN251 1-770-398-11 HOUSING, CONNECTOR(PC BOARD)5P
< DIODE >
D251 8-719-046-43 LED SEL5421E-TP15 (ª)
D252 8-719-046-43 LED SEL5421E-TP15 (·)
< RESISTOR >
R251 1-247-807-31 CARBON 100 5% 1/4W
R252 1-249-406-11 CARBON 120 5% 1/4W
R253 1-249-406-11 CARBON 120 5% 1/4W
R254 1-249-407-11 CARBON 150 5% 1/4W
R255 1-249-408-11 CARBON 180 5% 1/4W
R256 1-249-409-11 CARBON 220 5% 1/4W
< SWITCH >
S251 1-554-303-21 SWITCH, TACTILE (ª)
S252 1-554-303-21 SWITCH, TACTILE (·)
S253 1-554-303-21 SWITCH, TACTILE (p)
S254 1-554-303-21 SWITCH, TACTILE ())
S255 1-554-303-21 SWITCH, TACTILE (0)
S256 1-554-303-21 SWITCH, TACTILE (DIRECTION)
S257 1-554-303-21 SWITCH, TACTILE (DOLBY NR)
************************************************************
* 1-658-771-11 TC (P) SWITCH BOARD
*******************
< DIODE >
D262 8-719-046-36 LED SEL5921A-TH15 (PAUSE)
< LEAD, JUMPER >
* JW305 1-535-730-21 LEAD, JUMPER (OFC)
* JW306 1-535-730-21 LEAD, JUMPER (OFC)
* JW307 1-535-730-21 LEAD, JUMPER (OFC)
* JW308 1-535-730-21 LEAD, JUMPER (OFC)
< RESISTOR >
R264 1-249-408-11 CARBON 180 5% 1/4W
R265 1-249-409-11 CARBON 220 5% 1/4W
R266 1-249-410-11 CARBON 270 5% 1/4W
R267 1-249-411-11 CARBON 330 5% 1/4W
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
––––––– ––––––– –––––––––– ––––––– ––––––– ––––––– –––––––––– ––––––
TC (P) SWITCH
TC (B) SWITCH
TC (A) SWITCH
MOTOR (TURN)
SENSOR
