– 53 –
< SWITCH >
S265 1-554-303-21 SWITCH, TACTILE (CD SYNCHRO)
S266 1-554-303-21 SWITCH, TACTILE (HI-SPEED DUBBING)
S267 1-554-303-21 SWITCH, TACTILE (r REC)
S268 1-554-303-21 SWITCH, TACTILE (PAUSE)
************************************************************
MISCELLANEOUS
***************
57 1-773-022-11 WIRE (FLAT TYPE) (15 CORE)
66 1-769-961-11 WIRE (FLAT TYPE) (11 CORE)
67 1-773-167-11 WIRE (FLAT TYPE) (21 CORE)
257 1-452-824-11 MAGNET
258 1-776-042-11 WIRE (FLAT TYPE) (8 CORE)
266 1-776-222-11 WIRE (FLAT TYPE) (19 CORE)
! 301 8-848-367-11 DEVICE, OPTICAL KSS-213B / K-N
302 1-769-069-11 WIRE (FLAT TYPE) (16 CORE)
HP101 1-500-093-11 HEAD, MAGNETIC (PLAYBACK)
HRPE1011-500-094-11 HEAD, MAGNETIC (REC/PB/ERASE)
M1 A-2004-409-A MOTOR ASSY, CAPSTAN
M2 A-2004-410-A MOTOR ASSY, DC (TRIGGER)
M101 X-4917-523-4 BASE (OUTSERT)ASSY (SPINDLE MOTOR)
M102 X-4917-504-1 MOTOR ASSY (SLED MOTOR)
M701 A-4660-586-A MOTOR ASSY
M801 A-4660-586-A MOTOR ASSY (SLIDE MOTOR)
S851 1-473-335-11 ENCODER, ROTARY
************************************************************
ACCESSORIES & PACKING MATERIALS
********************************
1-501-721-11 ANTENNA (LOOP)
3-800-829-31 MANUAL, INSTRUCTION (ENGLISH)(UK)
3-800-829-41 MANUAL, INSTRUCTION (ENGLISH,FRENCH,
SPANISH,PORTUGUESE)(AEP)
3-800-829-51 MANUAL, INSTRUCTION (GERMAN,DUTCH,
ITALIAN)(AEP,Italian)
3-800-829-61 MANUAL, INSTRUCTION (GERMAN)(German)
3-800-829-71 MANUAL, INSTRUCTION (DANISH,FINNISH,
SWEDISH)(AEP)
* 4-979-071-01 CUSHION (HTC) (FRONT)
* 4-979-072-01 CUSHION (HTC) (REAR)
* 4-980-778-01 CARTON, INDIVIDUAL
************************************************************
*****************
HARDWARE LIST
*****************
#1 7-685-646-79 SCREW +BVTP 3X8 TYPE2 N-S
#2 7-685-647-79 SCREW +BVTP 3X10 TYPE2 N-S
#3 7-685-131-19 SCREW +BTP 2.6X4 TYPE2 N-S
#4 7-621-770-67 SCREW +BVTT 2.6X6 (S)
#5 7-685-534-19 SCREW +BTP 2.6X8 TYPE2 N-S
#6 7-621-775-10 SCREW +B 2.6X4
#7 7-621-775-00 SCREW +B 2.6X3
#8 7-623-921-01 RING, RETAINING, CAPSTAN
#9 7-621-255-15 SCREW +P 2X3
#10 7-685-533-19 SCREW +BTP 2.6X6 TYPE2 N-S
#11 7-685-871-01 SCREW +BVTT 3X6 (S)
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
––––––– ––––––– –––––––––– ––––––– ––––––– ––––––– –––––––––– ––––––
The components identified by mark
! or dotted line with mark ! are criti-
cal for safety.
Replace only with part number speci-
fied.
TC (P) SWITCH
