76
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
HCD-XG80/XG700
R661 1-249-410-11 CARBON 270 5% 1/4W
< SWITCH >
S601 1-762-875-21 SWITCH, KEYBOARD (DISPLAY)
S602 1-762-875-21 SWITCH, KEYBOARD (SPECTRUM ANALYZER)
S603 1-762-875-21 SWITCH, KEYBOARD (TIMER SELECT)
S604 1-762-875-21 SWITCH, KEYBOARD (SLEEP)
S605 1-762-875-21 SWITCH, KEYBOARD (c/CLOCK SET)
S606 1-762-875-21 SWITCH, KEYBOARD (GAME)
S607 1-762-875-21 SWITCH, KEYBOARD (FUNCTION)
S608 1-762-875-21 SWITCH, KEYBOARD (I/1)
S609 1-762-875-21 SWITCH, KEYBOARD
(POWER SAVE/DEMO (STANDBY))
< VIBRATOR >
X601 1-781-312-11 VIBRATOR, CERAMIC (12.5MHz)
**************************************************************
PANEL VR BOARD
***************
< CAPACITOR >
C701 1-162-294-31 CERAMIC 0.001uF 10% 50V
C702 1-162-294-31 CERAMIC 0.001uF 10% 50V
C703 1-162-294-31 CERAMIC 0.001uF 10% 50V
C704 1-104-664-11 ELECT 47uF 20% 16V
C705 1-162-306-11 CERAMIC 0.01uF 30% 16V
C711 1-162-306-11 CERAMIC 0.01uF 30% 16V
C712 1-162-306-11 CERAMIC 0.01uF 30% 16V
C713 1-164-159-21 CERAMIC 0.1uF 50V
C714 1-104-664-11 ELECT 47uF 20% 16V
C715 1-162-306-11 CERAMIC 0.01uF 30% 16V
< CONNECTOR >
CN701 1-568-838-11 SOCKET, CONNECTOR 21P
CN702 1-770-010-21 CONNECTOR, BOARD TO BOARD 4P
< LED >
D701 8-719-058-03 LED SEL5423E-TP15 (MOVIE)
D702 8-719-058-03 LED SEL5423E-TP15 (ROCK)
D703 8-719-058-03 LED SEL5423E-TP15 (REGGAE)
D704 8-719-058-03 LED SEL5423E-TP15 (GUITAR)
D705 8-719-058-03 LED SEL5423E-TP15 (SAMBA)
D706 8-719-058-03 LED SEL5423E-TP15 (JAZZ)
D707 8-719-058-03 LED SEL5423E-TP15 (TANGO)
D708 8-719-058-03 LED SEL5423E-TP15 (DANCE)
D709 8-719-058-03 LED SEL5423E-TP15 (GAME)
D710 8-719-058-03 LED SEL5423E-TP15 (SALSA)
D713 8-719-058-03 LED SEL5423E-TP15 (TUNER/BAND)
D714 8-719-058-04 LED SEL5223S-TP15 (ENTER)
D715 8-719-058-04 LED SEL5223S-TP15 (GUITAR DISTORTION)
D716 8-719-058-04 LED SEL5223S-TP15 (ENTER/NEXT)
D717 8-719-058-04 LED SEL5223S-TP15 (GROOVE)
D718 8-719-058-04 LED SEL5223S-TP15 (SUPER WOOFER)
D719 8-719-057-97 LED SEL5923A-TP15 (SURROUND)
< IC >
IC701 8-759-567-59 IC NJU3716L
IC702 8-759-827-68 IC NJL62H400A-1
(REMOTE CONTROL RECEIVER)
< COIL >
L701 1-410-509-11 INDUCTOR 10uH
< RESISTOR >
R701 1-249-411-11 CARBON 330 5% 1/4W
R702 1-249-413-11 CARBON 470 5% 1/4W
R703 1-249-414-11 CARBON 560 5% 1/4W
R704 1-249-415-11 CARBON 680 5% 1/4W
R705 1-249-417-11 CARBON 1K 5% 1/4W
R706 1-249-418-11 CARBON 1.2K 5% 1/4W
R707 1-249-420-11 CARBON 1.8K 5% 1/4W
R708 1-249-422-11 CARBON 2.7K 5% 1/4W
R709 1-247-843-11 CARBON 3.3K 5% 1/4W
R710 1-249-425-11 CARBON 4.7K 5% 1/4W
R711 1-249-427-11 CARBON 6.8K 5% 1/4W
R712 1-249-429-11 CARBON 10K 5% 1/4W
R713 1-249-431-11 CARBON 15K 5% 1/4W
R714 1-249-434-11 CARBON 27K 5% 1/4W
R715 1-249-411-11 CARBON 330 5% 1/4W
R716 1-249-413-11 CARBON 470 5% 1/4W
R717 1-249-414-11 CARBON 560 5% 1/4W
R718 1-249-415-11 CARBON 680 5% 1/4W
R719 1-249-417-11 CARBON 1K 5% 1/4W
R720 1-249-418-11 CARBON 1.2K 5% 1/4W
R721 1-249-420-11 CARBON 1.8K 5% 1/4W
R722 1-249-422-11 CARBON 2.7K 5% 1/4W
R723 1-247-843-11 CARBON 3.3K 5% 1/4W
R724 1-249-425-11 CARBON 4.7K 5% 1/4W
R725 1-249-420-11 CARBON 1.8K 5% 1/4W
R726 1-249-422-11 CARBON 2.7K 5% 1/4W
R727 1-247-843-11 CARBON 3.3K 5% 1/4W
R728 1-249-425-11 CARBON 4.7K 5% 1/4W
R729 1-249-427-11 CARBON 6.8K 5% 1/4W
R730 1-249-429-11 CARBON 10K 5% 1/4W
(XG700)
R734 1-249-417-11 CARBON 1K 5% 1/4W
R735 1-249-417-11 CARBON 1K 5% 1/4W
R736 1-249-401-11 CARBON 47 5% 1/4W
R737 1-247-807-31 CARBON 100 5% 1/4W
R738 1-247-807-31 CARBON 100 5% 1/4W
R739 1-247-807-31 CARBON 100 5% 1/4W
R740 1-249-429-11 CARBON 10K 5% 1/4W
R771 1-249-403-11 CARBON 68 5% 1/4W
R772 1-249-403-11 CARBON 68 5% 1/4W
R773 1-249-403-11 CARBON 68 5% 1/4W
R774 1-249-403-11 CARBON 68 5% 1/4W
R775 1-249-403-11 CARBON 68 5% 1/4W
R776 1-249-403-11 CARBON 68 5% 1/4W
R777 1-249-403-11 CARBON 68 5% 1/4W
R778 1-249-403-11 CARBON 68 5% 1/4W
R779 1-249-403-11 CARBON 68 5% 1/4W
R780 1-249-403-11 CARBON 68 5% 1/4W
R783 1-249-403-11 CARBON 68 5% 1/4W
R784 1-249-407-11 CARBON 150 5% 1/4W
R785 1-249-407-11 CARBON 150 5% 1/4W
PANEL FL PANEL VR
To Next Page
