Sony HCD-XGR60 - IC601 Pin Functions (Panel FL Board)

48
HCD-XGR6/XGR60
• IC601 MB90M407APF-G-112-BND DISPLAY CONTROL (PANEL FL Board)
Description
Pin NamePin No. I/O
1 GR-16 O FLD grid output
2 GR-15 O FLD grid output
3 GR-14 O FLD grid output
4 GR-13 O FLD grid output
5 GR-12 O FLD grid output
6 GR-11 O FLD grid output
7 GR-10 O FLD grid output
8 GR-9 O FLD grid output
9 GR-8 O FLD grid output
10 GR-7 O FLD grid output
11 VSS-IO — Ground
12 GR-6 O FLD grid output
13 GR-5 O FLD grid output
14 GR-4 O FLD grid output
15 GR-3 O FLD grid output
16 GR-2 O FLD grid output
17 GR-1 O FLD grid output
18 SEG-1 O FLD segment output
19 SEG-2 O FLD segment output
20 SEG-3 O FLD segment output
21 SEG-4 O FLD segment output
22 SEG-5 O FLD segment output
23 VDD-FIP — Power supply (+3.3V)
24 SEG-6 O FLD segment output
25 SEG-7 O FLD segment output
26 SEG-8 O FLD segment output
27 SEG-9 O FLD segment output
28 SEG-10 O FLD segment output
29 SEG-11 O FLD segment output
30 SEG-12 O FLD segment output
31 SEG-13 O FLD segment output
32 SEG-14 O FLD segment output
33 SEG-15 O FLD segment output
34 SEG-16 O FLD segment output
35 SEG-17 O FLD segment output
36 SEG-18 O FLD segment output
37 SEG-19 O FLD segment output
38 SEG-20 O FLD segment output
39 SEG-21 O FLD segment output
40 SEG-22 O FLD segment output
41 SEG-23 O FLD segment output
42 VSS-IO — Ground
43 SEG-24 O FLD segment output
44 SEG-25 O FLD segment output
45 NO USED O Not used (open)
46 NO USED O Not used (open)
47 NO USED O Not used (open)
48 VKK — Power supply (-35V)
49 MD0 I Not used (pull up with resistor)
50 MD1/VDD-VFT I Not used (pull up with resistor)
51 MD2 I Not used (pull down with resistor)
52 D-SW I CD lid open/close detect signal input
53 DIST O Guitar distortion ON/OFF signal output
