Sony HCD-XGR60 - Main Board Components (cont.)

63
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
HCD-XGR6/XGR60
CN371 1-784-776-11 CONNECTOR, FFC 15P
CN401 1-568-838-11 CONNECTOR, FFC 21P
CN411 1-785-321-11 PIN, CONNECTOR (STRAIGHT) 9P
CN431 1-784-780-11 CONNECTOR, FFC 19P
CN441 1-563-614-31 CONNECTOR, FLEXIBLE 11P
CN722 1-691-767-11 PLUG (MICRO CONNECTOR) 5P
CN901 1-778-982-21 CONNECTOR, BOARD TO BOARD 13P
CN902 1-778-982-21 CONNECTOR, BOARD TO BOARD 13P
CN903 1-785-315-11 PIN, CONNECTOR (STRAIGHT) 3P
CN961 1-564-506-11 PLUG, CONNECTOR 3P
< DIODE >
D381 8-719-988-61 DIODE 1SS355TE-17
D382 8-719-988-61 DIODE 1SS355TE-17
D431 8-719-988-61 DIODE 1SS355TE-17
D802 8-719-988-61 DIODE 1SS355TE-17
D803 8-719-988-61 DIODE 1SS355TE-17
D805 8-719-988-61 DIODE 1SS355TE-17
D806 8-719-988-61 DIODE 1SS355TE-17
D807 8-719-988-61 DIODE 1SS355TE-17
D808 8-719-988-61 DIODE 1SS355TE-17
D809 8-719-210-33 DIODE EC10DS2
D810 8-719-210-33 DIODE EC10DS2
D911 8-719-210-33 DIODE EC10DS2
D912 8-719-210-33 DIODE EC10DS2
D913 8-719-210-33 DIODE EC10DS2
< FERRITE BEAD >
FB402 1-414-772-11 FERRITE 0UH
FB403 1-414-772-11 FERRITE 0UH
FB404 1-414-772-11 FERRITE 0UH
FB516 1-414-772-11 FERRITE 0UH
FB562 1-414-772-11 FERRITE 0UH
FB599 1-414-772-11 FERRITE 0UH
< IC >
IC111 6-701-686-01 IC M61519FPD60G
IC181 8-759-009-06 IC MC14052BFEL
IC301 6-701-655-01 IC HA12236F
IC321 8-759-143-54 IC uPC1330HA
IC341 8-759-100-96 IC NJM4558M-TE2
IC451 8-749-019-25 IC TOTX141 (CD DIGITAL OUT OPTICAL)
IC501 6-801-051-01 IC M30620MCN-A01FP
IC601 8-759-100-96 IC NJM4558M-TE2
IC801 8-759-533-04 IC M62703ML-E1
IC911 8-759-231-09 IC TA8662N
IC921 8-759-039-69 IC uPC7805AHF
IC922 6-701-760-01 IC uPC3504AHF
IC931 8-759-604-32 IC M5F7810L
IC961 8-759-088-08 IC uPC7812AHF
< JACK >
J701 1-691-887-11 JACK, PIN 6P (PHONO IN, MD IN/OUT)
J702 1-573-028-31 JACK, PIN 4P (DJ MIX) (XGR6,XGR60:MX)
J721 1-774-227-11 JACK, PIN 1P (VIDEO OUT)
< JUMPER RESISTOR >
JR1 1-216-295-00 SHORT 0
JR2 1-216-295-00 SHORT 0
JR3 1-216-295-00 SHORT 0
JR4 1-216-295-00 SHORT 0
JR5 1-216-295-00 SHORT 0
JR6 1-216-295-00 SHORT 0
JR7 1-216-295-00 SHORT 0
JR12 1-216-295-00 SHORT 0
JR13 1-216-296-11 SHORT 0
JR14 1-216-296-11 SHORT 0
JR15 1-216-295-00 SHORT 0
JR16 1-216-295-00 SHORT 0
JR17 1-216-295-00 SHORT 0
JR18 1-216-295-00 SHORT 0
JR19 1-216-296-11 SHORT 0
JR20 1-216-295-00 SHORT 0
JR21 1-216-295-00 SHORT 0
JR22 1-216-295-00 SHORT 0
JR23 1-216-295-00 SHORT 0
JR27 1-216-295-00 SHORT 0
JR28 1-216-296-11 SHORT 0
JR29 1-216-295-00 SHORT 0
JR181 1-216-295-00 SHORT 0
JR182 1-216-295-00 SHORT 0
JR191 1-216-295-00 SHORT 0
JR192 1-216-295-00 SHORT 0
JR301 1-216-295-00 SHORT 0
JR303 1-216-295-00 SHORT 0
JR351 1-216-295-00 SHORT 0
JR353 1-216-295-00 SHORT 0
JR721 1-216-295-00 SHORT 0
JR722 1-216-295-00 SHORT 0
JR723 1-216-295-00 SHORT 0
JR910 1-216-296-11 SHORT 0 (XGR6)
< COIL >
L301 1-412-032-11 INDUCTOR CHIP 100uH
L321 1-410-780-11 INDUCTOR 27mH
L322 1-410-780-11 INDUCTOR 27mH
L331 1-412-033-11 INDUCTOR CHIP 220uH
L451 1-412-032-11 INDUCTOR CHIP 100uH
< TRANSISTOR >
Q111 8-729-048-96 TRANSISTOR 2SK1825
Q112 8-729-048-96 TRANSISTOR 2SK1825
Q113 8-729-048-96 TRANSISTOR 2SK1825
Q114 8-729-141-30 TRANSISTOR 2SC3623A-LK
Q115 8-729-141-30 TRANSISTOR 2SC3623A-LK
Q116 8-729-141-30 TRANSISTOR 2SC3623A-LK
Q161 8-729-048-96 TRANSISTOR 2SK1825
Q162 8-729-048-96 TRANSISTOR 2SK1825
Q163 8-729-048-96 TRANSISTOR 2SK1825
Q164 8-729-141-30 TRANSISTOR 2SC3623A-LK
Q165 8-729-029-40 TRANSISTOR DTA124ESA
Q166 8-729-620-05 TRANSISTOR 2SC2603-EF
Q167 8-729-029-40 TRANSISTOR DTA124ESA
Q168 8-729-029-86 TRANSISTOR DTC124ESA
Q169 8-729-029-40 TRANSISTOR DTA124ESA
Q170 8-729-029-86 TRANSISTOR DTC124ESA
Q181 8-729-029-86 TRANSISTOR DTC124ESA
Q182 8-729-029-86 TRANSISTOR DTC124ESA
Q321 8-729-029-86 TRANSISTOR DTC124ESA
Q322 8-729-029-40 TRANSISTOR DTA124ESA
Q331 8-729-113-07 TRANSISTOR 2SC2001TP-K
Q332 8-729-113-07 TRANSISTOR 2SC2001TP-K
MAIN
