Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
HCD-XGR90AV
PA
The components identified by mark 0 or dotted line
with mark 0 are critical for safety.
Replace only with part number specified.
C815 1-126-959-11 ELECT 0.47uF 20% 50V
C830 1-107-714-11 ELECT 10uF 20% 50V
C831 1-126-964-11 ELECT 10uF 20% 50V
C832 1-126-967-11 ELECT 47uF 20% 50V
C841 1-127-811-11 ELECT 3300uF 20% 50V
C842 1-127-814-11 ELECT 3300uF 20% 80V
C844 1-137-749-11 MYLAR 0.1uF 100V
C845 1-126-943-11 ELECT 2200uF 20% 25V
C847 1-164-159-21 CERAMIC 0.1uF 50V
C848 1-164-159-21 CERAMIC 0.1uF 50V
C849 1-164-159-21 CERAMIC 0.1uF 50V
C850 1-107-721-11 ELECT 4.7uF 20% 100V
C851 1-128-582-11 ELECT 10uF 20% 100V
C852 1-162-290-31 CERAMIC 470PF 10% 50V
C853 1-162-286-21 CERAMIC 220PF 10% 50V
C854 1-126-967-11 ELECT 47uF 20% 50V
C857 1-128-560-11 ELECT 22uF 20% 100V
C858 1-164-159-21 CERAMIC 0.1uF 50V
C859 1-164-159-21 CERAMIC 0.1uF 50V
C861 1-130-491-00 MYLAR 0.047uF 5% 50V
C862 1-130-491-00 MYLAR 0.047uF 5% 50V
C863 1-126-961-11 ELECT 2.2uF 20% 50V
C864 1-126-964-11 ELECT 10uF 20% 50V
C891 1-127-811-11 ELECT 3300uF 20% 50V
C892 1-127-814-11 ELECT 3300uF 20% 80V
C894 1-137-749-11 MYLAR 0.1uF 100V
C895 1-107-721-11 ELECT 4.7uF 20% 100V
C902 1-164-159-21 CERAMIC 0.1uF 50V
C903 1-126-933-11 ELECT 100uF 20% 16V
C904 1-126-964-11 ELECT 10uF 20% 50V
C905 1-126-968-11 ELECT 100uF 20% 50V
C906 1-126-943-11 ELECT 2200uF 20% 25V
C909 1-164-159-21 CERAMIC 0.1uF 50V
< CONNECTOR >
CN803 1-778-981-21 CONNECTOR, BOARD TO BOARD 13P
CN804 1-778-981-21 CONNECTOR, BOARD TO BOARD 13P
CN806 1-785-316-11 PIN, CONNECTOR (STRAIGHT) 4P
CN904 1-785-316-11 PIN, CONNECTOR (STRAIGHT) 4P
< DIODE >
D401 8-719-991-33 DIODE 1SS133T-77
D402 8-719-991-33 DIODE 1SS133T-77
D403 8-719-991-33 DIODE 1SS133T-77
D404 8-719-991-33 DIODE 1SS133T-77
D405 8-719-991-33 DIODE 1SS133T-77
D406 8-719-991-33 DIODE 1SS133T-77
D407 8-719-991-33 DIODE 1SS133T-77
D408 8-719-991-33 DIODE 1SS133T-77
D409 8-719-991-33 DIODE 1SS133T-77
D410 8-719-991-33 DIODE 1SS133T-77
D801 8-719-991-33 DIODE 1SS133T-77
D802 8-719-110-39 DIODE RD15ESB1
D803 8-719-991-33 DIODE 1SS133T-77
D804 8-719-991-33 DIODE 1SS133T-77
D805 8-719-991-33 DIODE 1SS133T-77
D831 8-719-510-68 DIODE D5SBA204101
D833 8-719-200-82 DIODE 11ES2
D834 8-719-200-82 DIODE 11ES2
D835 8-719-200-82 DIODE 11ES2
D836 8-719-200-82 DIODE 11ES2
D841 8-719-200-82 DIODE 11ES2
D842 8-719-200-82 DIODE 11ES2
D843 8-719-200-82 DIODE 11ES2
D844 8-719-200-82 DIODE 11ES2
D851 8-719-991-33 DIODE 1SS133T-77
D852 8-719-110-39 DIODE RD15ESB1
D853 8-719-991-33 DIODE 1SS133T-77
D902 8-719-200-82 DIODE 11ES2
D903 8-719-200-82 DIODE 11ES2
D904 8-719-200-82 DIODE 11ES2
D905 8-719-200-82 DIODE 11ES2
D911 8-719-982-37 DIODE MTZJ-39C (E)
D911 8-719-982-24 DIODE MTZJ-33A (AUS)
D912 8-719-109-89 DIODE RD5.6ESB2
< IC >
IC801 8-749-017-05 IC STK412-040
IC901 6-701-760-01 IC uPC3504AHF
< COIL >
L403 1-422-009-13 COIL, AIR-CORE
L404 1-422-009-13 COIL, AIR-CORE
L405 1-422-009-13 COIL, AIR-CORE
< TRANSISTOR >
Q401 8-729-029-40 TRANSISTOR DTA124ESA
Q402 8-729-140-84 TRANSISTOR 2SC1841-PAFAEA
Q403 8-729-029-40 TRANSISTOR DTA124ESA
Q407 8-729-029-86 TRANSISTOR DTC124ESA
Q431 8-729-620-05 TRANSISTOR 2SC2603-EF
Q432 8-729-119-76 TRANSISTOR 2SA1175-HFE
Q433 8-729-620-05 TRANSISTOR 2SC2603-EF
Q434 8-729-620-05 TRANSISTOR 2SC2603-EF
Q437 8-729-620-05 TRANSISTOR 2SC2603-EF
Q439 8-729-620-05 TRANSISTOR 2SC2603-EF
Q801 8-729-140-84 TRANSISTOR 2SC1841-PAFAEA
Q803 8-729-140-82 TRANSISTOR 2SA988-PAFAEA
Q804 8-729-140-84 TRANSISTOR 2SC1841-PAFAEA
Q805 8-729-231-55 TRANSISTOR 2SC2878-AB
Q831 8-729-029-86 TRANSISTOR DTC124ESA
Q832 8-729-620-05 TRANSISTOR 2SC2603-EF
Q833 8-729-029-40 TRANSISTOR DTA124ESA
Q834 8-729-140-84 TRANSISTOR 2SC1841-PAFAEA
Q851 8-729-140-84 TRANSISTOR 2SC1841-PAFAEA
Q855 8-729-231-55 TRANSISTOR 2SC2878-AB
Q901 8-729-620-05 TRANSISTOR 2SC2603-EF
Q903 8-729-209-60 TRANSISTOR 2SB1375
Q908 8-729-119-76 TRANSISTOR 2SA1175-HFE
< RESISTOR >
0R401 1-216-430-11 METAL OXIDE 390 5% 1W
0R402 1-216-431-11 METAL OXIDE 560 5% 1W
R406 1-249-437-11 CARBON 47K 5% 1/4W
R407 1-249-437-11 CARBON 47K 5% 1/4W
R408 1-249-440-11 CARBON 82K 5% 1/4W
R409 1-249-437-11 CARBON 47K 5% 1/4W
R416 1-249-389-11 CARBON 4.7 5% 1/4W F
R417 1-249-389-11 CARBON 4.7 5% 1/4W F
R418 1-249-389-11 CARBON 4.7 5% 1/4W F
