72
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
HCD-XGR90AV
PA
The components identified by mark 0 or dotted line
with mark 0 are critical for safety.
Replace only with part number specified.
PANEL FL
R419 1-249-389-11 CARBON 4.7 5% 1/4W F
R420 1-249-389-11 CARBON 4.7 5% 1/4W F
R421 1-249-389-11 CARBON 4.7 5% 1/4W F
R422 1-260-076-11 CARBON 10 5% 1/2W
R423 1-260-076-11 CARBON 10 5% 1/2W
R424 1-260-076-11 CARBON 10 5% 1/2W
R425 1-249-437-11 CARBON 47K 5% 1/4W
R429 1-249-437-11 CARBON 47K 5% 1/4W
R431 1-249-438-11 CARBON 56K 5% 1/4W
R432 1-249-437-11 CARBON 47K 5% 1/4W
R434 1-249-433-11 CARBON 22K 5% 1/4W
R437 1-249-429-11 CARBON 10K 5% 1/4W
R439 1-249-425-11 CARBON 4.7K 5% 1/4W F
R440 1-249-433-11 CARBON 22K 5% 1/4W
R441 1-249-435-11 CARBON 33K 5% 1/4W
R442 1-249-435-11 CARBON 33K 5% 1/4W
R443 1-249-434-11 CARBON 27K 5% 1/4W
R444 1-249-439-11 CARBON 68K 5% 1/4W
R446 1-249-429-11 CARBON 10K 5% 1/4W
R447 1-249-437-11 CARBON 47K 5% 1/4W
R450 1-249-437-11 CARBON 47K 5% 1/4W
R801 1-249-417-11 CARBON 1K 5% 1/4W F
R802 1-249-437-11 CARBON 47K 5% 1/4W
R803 1-249-414-11 CARBON 560 5% 1/4W F
R804 1-249-435-11 CARBON 33K 5% 1/4W
R805 1-216-436-00 METAL OXIDE 3.9K 5% 1W
R806 1-216-436-00 METAL OXIDE 3.9K 5% 1W
0R807 1-212-881-11 FUSIBLE 100 5% 1/4W
0R808 1-220-893-11 METAL 0.22 10% 5W
R809 1-260-076-11 CARBON 10 5% 1/2W
R810 1-249-437-11 CARBON 47K 5% 1/4W
R811 1-249-417-11 CARBON 1K 5% 1/4W F
R812 1-249-431-11 CARBON 15K 5% 1/4W
R813 1-249-441-11 CARBON 100K 5% 1/4W
R814 1-249-421-11 CARBON 2.2K 5% 1/4W F
R815 1-249-433-11 CARBON 22K 5% 1/4W
R816 1-249-429-11 CARBON 10K 5% 1/4W
R817 1-249-437-11 CARBON 47K 5% 1/4W
R818 1-249-409-11 CARBON 220 5% 1/4W F
R819 1-249-439-11 CARBON 68K 5% 1/4W
0R820 1-202-972-61 FUSIBLE 1 5% 1/4W
R821 1-249-435-11 CARBON 33K 5% 1/4W
R822 1-249-433-11 CARBON 22K 5% 1/4W
R823 1-249-433-11 CARBON 22K 5% 1/4W
R824 1-249-413-11 CARBON 470 5% 1/4W F
0R825 1-215-891-11 METAL OXIDE 680 5% 2W
R827 1-249-441-11 CARBON 100K 5% 1/4W
R828 1-247-903-00 CARBON 1M 5% 1/4W
R831 1-249-441-11 CARBON 100K 5% 1/4W
R832 1-249-441-11 CARBON 100K 5% 1/4W
R833 1-249-432-11 CARBON 18K 5% 1/4W
R834 1-249-429-11 CARBON 10K 5% 1/4W
R835 1-249-437-11 CARBON 47K 5% 1/4W
R836 1-249-417-11 CARBON 1K 5% 1/4W F
R837 1-249-435-11 CARBON 33K 5% 1/4W
R838 1-249-435-11 CARBON 33K 5% 1/4W
R839 1-249-441-11 CARBON 100K 5% 1/4W
R840 1-249-402-11 CARBON 56 5% 1/4W F
R851 1-249-417-11 CARBON 1K 5% 1/4W F
R852 1-249-437-11 CARBON 47K 5% 1/4W
R853 1-249-414-11 CARBON 560 5% 1/4W F
0R855 1-215-891-11 METAL OXIDE 680 5% 2W
0R857 1-212-881-11 FUSIBLE 100 5% 1/4W
0R858 1-220-893-11 METAL 0.22 10% 5W
R859 1-260-076-11 CARBON 10 5% 1/2W
R860 1-249-437-11 CARBON 47K 5% 1/4W
R861 1-249-417-11 CARBON 1K 5% 1/4W F
R862 1-249-431-11 CARBON 15K 5% 1/4W
R863 1-249-441-11 CARBON 100K 5% 1/4W
R864 1-249-425-11 CARBON 4.7K 5% 1/4W F
R865 1-249-433-11 CARBON 22K 5% 1/4W
R866 1-249-429-11 CARBON 10K 5% 1/4W
R867 1-249-421-11 CARBON 2.2K 5% 1/4W F
R868 1-249-409-11 CARBON 220 5% 1/4W F
R880 1-249-402-11 CARBON 56 5% 1/4W F
0R888 1-220-893-11 METAL 0.22 10% 5W
R889 1-249-441-11 CARBON 100K 5% 1/4W
0R898 1-220-893-11 METAL 0.22 10% 5W
R901 1-249-429-11 CARBON 10K 5% 1/4W
R902 1-249-441-11 CARBON 100K 5% 1/4W
R903 1-249-429-11 CARBON 10K 5% 1/4W
R904 1-249-417-11 CARBON 1K 5% 1/4W F
R905 1-249-429-11 CARBON 10K 5% 1/4W
R906 1-247-807-31 CARBON 100 5% 1/4W
R907 1-247-807-31 CARBON 100 5% 1/4W
R915 1-247-791-91 CARBON 22 5% 1/4W
0R916 1-215-915-11 METAL OXIDE 470 5% 3W
< RELEY >
RY401 1-515-920-11 RELAY <24V)
RY402 1-515-920-11 RELAY (24V)
RY403 1-515-920-11 RELAY (24V)
< THERMISTOR >
TH831 1-807-796-11 THERMISTOR
< TERMINAL >
TM401 1-537-925-62 TERMINAL BOARD 4P (FRONT SPEAKER)
TM402 1-537-510-31 TERMINAL BOARD 6P (SURROUND SPEAKER)
******************************************************
A-4727-623-A PANEL FL BOARD, COMPLETE
**********************
4-225-511-01 HOLDER FL TUBE
* 4-949-935-81 CUSHION (FL)
< CAPACITOR >
C601 1-162-294-31 CERAMIC 0.001uF 10% 50V
C602 1-126-947-11 ELECT 47uF 20% 16V
C603 1-162-306-11 CERAMIC 0.01uF 30% 16V
C604 1-126-947-11 ELECT 47uF 20% 16V
C605 1-162-306-11 CERAMIC 0.01uF 30% 16V
C606 1-126-963-11 ELECT 4.7uF 20% 50V
C607 1-164-159-21 CERAMIC 0.1uF 50V
C612 1-164-159-21 CERAMIC 0.1uF 50V
C614 1-126-947-11 ELECT 47uF 20% 16V
C615 1-126-964-11 ELECT 10uF 20% 50V
C616 1-162-303-11 CERAMIC 0.0033uF 30% 16V
C617 1-126-157-11 ELECT 10uF 20% 16V
