74
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
HCD-XGR90AV
PANEL VR
R680 1-249-411-11 CARBON 330 5% 1/4W
R681 1-249-437-11 CARBON 47K 5% 1/4W
R683 1-249-437-11 CARBON 47K 5% 1/4W
R684 1-249-417-11 CARBON 1K 5% 1/4W F
R685 1-249-417-11 CARBON 1K 5% 1/4W F
R686 1-249-437-11 CARBON 47K 5% 1/4W
R688 1-249-437-11 CARBON 47K 5% 1/4W
R689 1-249-417-11 CARBON 1K 5% 1/4W F
R690 1-249-417-11 CARBON 1K 5% 1/4W F
R691 1-249-413-11 CARBON 470 5% 1/4W F
R692 1-249-413-11 CARBON 470 5% 1/4W F
R693 1-249-429-11 CARBON 10K 5% 1/4W
R694 1-249-429-11 CARBON 10K 5% 1/4W
R695 1-247-807-31 CARBON 100 5% 1/4W
R696 1-247-807-31 CARBON 100 5% 1/4W
R697 1-247-807-31 CARBON 100 5% 1/4W
R698 1-249-415-11 CARBON 680 5% 1/4W F
R699 1-249-411-11 CARBON 330 5% 1/4W
R700 1-249-413-11 CARBON 470 5% 1/4W F
R901 1-249-437-11 CARBON 47K 5% 1/4W
R902 1-249-437-11 CARBON 47K 5% 1/4W
R903 1-249-437-11 CARBON 47K 5% 1/4W
R904 1-249-437-11 CARBON 47K 5% 1/4W
R905 1-249-417-11 CARBON 1K 5% 1/4W F
R906 1-249-417-11 CARBON 1K 5% 1/4W F
R907 1-249-417-11 CARBON 1K 5% 1/4W F
R908 1-249-417-11 CARBON 1K 5% 1/4W F
< SWITCH >
S601 1-762-875-21 SWITCH, KEYBOARD (SALSA)
S602 1-762-875-21 SWITCH, KEYBOARD (REGGAE)
S603 1-762-875-21 SWITCH, KEYBOARD (TANGO)
S604 1-762-875-21 SWITCH, KEYBOARD (SAMBA)
S605 1-762-875-21 SWITCH, KEYBOARD (MOVIE)
S606 1-762-875-21 SWITCH, KEYBOARD (GUITAR)
S607 1-762-875-21 SWITCH, KEYBOARD (ROCK)
S608 1-762-875-21 SWITCH, KEYBOARD (JAZZ)
S609 1-762-875-21 SWITCH, KEYBOARD (DANCE)
S610 1-762-875-21 SWITCH, KEYBOARD (GAME)
S611 1-762-875-21 SWITCH, KEYBOARD (SPECTRUM ANALYZER)
S612 1-762-875-21 SWITCH, KEYBOARD (DISPLAY)
S613 1-762-875-21 SWITCH, KEYBOARD (SLEEP)
S614 1-762-875-21 SWITCH, KEYBOARD (TIMER SELECT)
S615 1-762-875-21 SWITCH, KEYBOARD (c/CLOCK SET)
S616 1-762-875-21 SWITCH, KEYBOARD (FUNCTION)
S617 1-762-875-21 SWITCH, KEYBOARD (GAME)
S618 1-762-875-21 SWITCH, KEYBOARD (GAME MIXING)
S619 1-762-875-21 SWITCH, KEYBOARD
(POWER SAVE/DEMO (STANDBY))
S620 1-762-875-21 SWITCH, KEYBOARD ([/1)
< VIBRATOR >
X601 1-577-358-21 VIBRATOR, CERAMIC (4MHz)
******************************************************
A-4727-609-A PANEL VR BOARD, COMPLETE
**********************
< CAPACITOR >
C701 1-162-294-31 CERAMIC 0.001uF 10% 50V
C702 1-162-294-31 CERAMIC 0.001uF 10% 50V
C703 1-162-294-31 CERAMIC 0.001uF 10% 50V
C704 1-126-947-11 ELECT 47uF 20% 16V
C705 1-162-306-11 CERAMIC 0.01uF 30% 16V
C706 1-164-159-21 CERAMIC 0.1uF 50V
C707 1-162-306-11 CERAMIC 0.01uF 30% 16V
C708 1-162-306-11 CERAMIC 0.01uF 30% 16V
< CONNECTOR >
* CN701 1-568-865-11 SOCKET, CONNECTOR 23P
< DIODE >
D701 8-719-058-64 DIODE SEL5823A-TP15 (VU 1)
D702 8-719-058-64 DIODE SEL5823A-TP15 (VU 2)
D703 8-719-058-64 DIODE SEL5823A-TP15 (VU 3)
D704 8-719-058-64 DIODE SEL5823A-TP15 (VU 4)
D705 8-719-058-64 DIODE SEL5823A-TP15 (VU 5)
D706 8-719-058-64 DIODE SEL5823A-TP15 (VU 6)
D707 8-719-058-64 DIODE SEL5823A-TP15 (VU 7)
D708 8-719-058-64 DIODE SEL5823A-TP15 (VU 8)
D709 8-719-058-64 DIODE SEL5823A-TP15 (VU 9)
D710 8-719-058-04 DIODE SEL5223S-TP15 (VU 10)
D711 8-719-058-04 DIODE SEL5223S-TP15 (VU 11)
D712 8-719-058-04 DIODE SEL5223S-TP15 (VU 12)
D713 8-719-058-04 DIODE SEL5223S-TP15 (GROOVE)
D714 8-719-058-04 DIODE SEL5223S-TP15 (SUPER WOOFER)
D715 8-719-058-04 DIODE SEL5223S-TP15 (SURROUND)
D716 8-719-058-04 DIODE SEL5223S-TP15 (ENTER)
D717 8-719-058-04 DIODE SEL5223S-TP15 (GUITAR DISTORSION)
D719 8-719-058-03 DIODE SEL5423E-TP15 (TUNER/BAND)
D720 8-719-058-04 DIODE SEL5223S-TP15 (TUNER ENTER)
D721 8-719-057-97 DIODE SEL5923A-TP15 (PRO LOGIC)
D722 8-719-057-97 DIODE SEL5923A-TP15 (DVD 5.1CH)
< IC >
IC701 8-759-373-50 IC NJU3719L
< COIL >
L701 1-410-509-11 INDUCTOR 10uH
< RESISTOR >
R701 1-249-429-11 CARBON 10K 5% 1/4W
R702 1-247-807-31 CARBON 100 5% 1/4W
R703 1-247-807-31 CARBON 100 5% 1/4W
R704 1-247-807-31 CARBON 100 5% 1/4W
R705 1-249-417-11 CARBON 1K 5% 1/4W F
R706 1-249-417-11 CARBON 1K 5% 1/4W F
R707 1-249-417-11 CARBON 1K 5% 1/4W F
R708 1-249-419-11 CARBON 1.5K 5% 1/4W F
R709 1-249-419-11 CARBON 1.5K 5% 1/4W F
R710 1-249-421-11 CARBON 2.2K 5% 1/4W F
R711 1-247-843-11 CARBON 3.3K 5% 1/4W
R712 1-249-425-11 CARBON 4.7K 5% 1/4W F
R713 1-249-427-11 CARBON 6.8K 5% 1/4W F
R714 1-249-429-11 CARBON 10K 5% 1/4W
R715 1-249-431-11 CARBON 15K 5% 1/4W
R716 1-249-433-11 CARBON 22K 5% 1/4W
R718 1-249-415-11 CARBON 680 5% 1/4W F
R719 1-249-417-11 CARBON 1K 5% 1/4W F
R720 1-249-419-11 CARBON 1.5K 5% 1/4W F
R721 1-249-419-11 CARBON 1.5K 5% 1/4W F
PANEL FL
