75
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
HCD-XGR90AV
R722 1-249-421-11 CARBON 2.2K 5% 1/4W F
R723 1-247-843-11 CARBON 3.3K 5% 1/4W
R724 1-249-425-11 CARBON 4.7K 5% 1/4W F
R725 1-249-427-11 CARBON 6.8K 5% 1/4W F
R726 1-249-429-11 CARBON 10K 5% 1/4W
R727 1-249-431-11 CARBON 15K 5% 1/4W
R728 1-249-433-11 CARBON 22K 5% 1/4W
R729 1-249-435-11 CARBON 33K 5% 1/4W
R731 1-247-791-91 CARBON 22 5% 1/4W
R732 1-247-791-91 CARBON 22 5% 1/4W
R733 1-247-791-91 CARBON 22 5% 1/4W
R734 1-247-791-91 CARBON 22 5% 1/4W
R735 1-247-791-91 CARBON 22 5% 1/4W
R736 1-247-791-91 CARBON 22 5% 1/4W
R737 1-247-791-91 CARBON 22 5% 1/4W
R738 1-247-791-91 CARBON 22 5% 1/4W
R739 1-247-791-91 CARBON 22 5% 1/4W
R740 1-249-401-11 CARBON 47 5% 1/4W F
R741 1-249-401-11 CARBON 47 5% 1/4W F
R742 1-249-401-11 CARBON 47 5% 1/4W F
R743 1-247-807-31 CARBON 100 5% 1/4W
R744 1-247-807-31 CARBON 100 5% 1/4W
R745 1-247-807-31 CARBON 100 5% 1/4W
R746 1-247-807-31 CARBON 100 5% 1/4W
R747 1-247-807-31 CARBON 100 5% 1/4W
R749 1-247-791-91 CARBON 22 5% 1/4W
R750 1-247-807-31 CARBON 100 5% 1/4W
R751 1-247-791-91 CARBON 22 5% 1/4W
R752 1-247-791-91 CARBON 22 5% 1/4W
< SWITCH >
S700 1-473-392-11 ENCODER, ROTARY (VOLUME)
S701 1-762-875-21 SWITCH, KEYBOARD (GROOVE)
S702 1-762-875-21 SWITCH, KEYBOARD (SURROUND)
S703 1-762-875-21 SWITCH, KEYBOARD (EFFECT ON/OFF)
S704 1-762-875-21 SWITCH, KEYBOARD (P FILE)
S705 1-762-875-21 SWITCH, KEYBOARD (ENTER)
S706 1-762-875-21 SWITCH, KEYBOARD ( R )
S707 1-762-875-21 SWITCH, KEYBOARD ( r )
S708 1-762-875-21 SWITCH, KEYBOARD (t)
S709 1-762-875-21 SWITCH, KEYBOARD (T)
S710 1-762-875-21 SWITCH, KEYBOARD (MIX GUITAR/KARAOKE)
S711 1-762-875-21 SWITCH, KEYBOARD (GUITAR DISTORSION)
S713 1-762-875-21 SWITCH, KEYBOARD (SUPER WOOFER)
S714 1-762-875-21 SWITCH, KEYBOARD (SUPER WOOFER MODE)
S715 1-762-875-21 SWITCH, KEYBOARD (X-GROOVE)
S716 1-762-875-21 SWITCH, KEYBOARD (TUNER/BAND)
S717 1-762-875-21 SWITCH, KEYBOARD (TUNING –)
S718 1-762-875-21 SWITCH, KEYBOARD (TUNING +)
S719 1-762-875-21 SWITCH, KEYBOARD (FM MODE)
S720 1-762-875-21 SWITCH, KEYBOARD (TUNER ENTER)
S721 1-762-875-21 SWITCH, KEYBOARD (TUNER MEMORY)
S722 1-762-875-21 SWITCH, KEYBOARD (TUNING MODE)
S724 1-762-875-21 SWITCH, KEYBOARD (PRO LOGIC)
S725 1-762-875-21 SWITCH, KEYBOARD (DVD 5.1CH)
******************************************************
A-4727-611-A PROLOGIC BOARD, COMPLETE
***********************
< CAPACITOR >
C201 1-126-964-11 ELECT 10uF 20% 50V
C202 1-126-964-11 ELECT 10uF 20% 50V
C203 1-126-959-11 ELECT 0.47uF 20% 50V
C204 1-126-959-11 ELECT 0.47uF 20% 50V
C205 1-136-165-00 FILM 0.1uF 5% 50V
C206 1-136-165-00 FILM 0.1uF 5% 50V
C207 1-126-959-11 ELECT 0.47uF 20% 50V
C208 1-126-959-11 ELECT 0.47uF 20% 50V
C209 1-126-959-11 ELECT 0.47uF 20% 50V
C210 1-126-959-11 ELECT 0.47uF 20% 50V
C211 1-126-959-11 ELECT 0.47uF 20% 50V
C212 1-126-959-11 ELECT 0.47uF 20% 50V
C213 1-136-165-00 FILM 0.1uF 5% 50V
C214 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C215 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C216 1-126-960-11 ELECT 1uF 20% 50V
C217 1-130-479-00 MYLAR 0.0047uF 5% 50V
C218 1-130-471-00 MYLAR 0.001uF 5% 50V
C219 1-136-165-00 FILM 0.1uF 5% 50V
C220 1-136-169-00 FILM 0.22uF 5% 50V
C221 1-136-169-00 FILM 0.22uF 5% 50V
C222 1-136-165-00 FILM 0.1uF 5% 50V
C223 1-130-479-00 MYLAR 0.0047uF 5% 50V
C224 1-130-471-00 MYLAR 0.001uF 5% 50V
C225 1-126-960-11 ELECT 1uF 20% 50V
C226 1-130-480-00 MYLAR 0.0056uF 5% 50V
C227 1-136-161-00 FILM 0.047uF 5% 50V
C228 1-136-175-00 FILM 0.68uF 5% 50V
C229 1-136-169-00 FILM 0.22uF 5% 50V
C230 1-136-169-00 FILM 0.22uF 5% 50V
C231 1-126-963-11 ELECT 4.7uF 20% 50V
C232 1-126-963-11 ELECT 4.7uF 20% 50V
C233 1-136-169-00 FILM 0.22uF 5% 50V
C234 1-136-169-00 FILM 0.22uF 5% 50V
C235 1-136-165-00 FILM 0.1uF 5% 50V
C236 1-136-161-00 FILM 0.047uF 5% 50V
C237 1-136-161-00 FILM 0.047uF 5% 50V
C238 1-136-165-00 FILM 0.1uF 5% 50V
C239 1-136-165-00 FILM 0.1uF 5% 50V
C240 1-136-157-00 FILM 0.022uF 5% 50V
C241 1-136-157-00 FILM 0.022uF 5% 50V
C242 1-136-165-00 FILM 0.1uF 5% 50V
C243 1-130-469-00 MYLAR 680PF 5% 50V
C244 1-136-153-00 FILM 0.01uF 5% 50V
C245 1-136-153-00 FILM 0.01uF 5% 50V
C246 1-130-469-00 MYLAR 680PF 5% 50V
C247 1-136-153-00 FILM 0.01uF 5% 50V
C248 1-136-153-00 FILM 0.01uF 5% 50V
C249 1-126-947-11 ELECT 47uF 20% 16V
C250 1-130-481-00 MYLAR 0.0068uF 5% 50V
C251 1-126-963-11 ELECT 4.7uF 20% 50V
C252 1-126-934-11 ELECT 220uF 20% 16V
C253 1-126-934-11 ELECT 220uF 20% 16V
C255 1-126-964-11 ELECT 10uF 20% 50V
C256 1-126-964-11 ELECT 10uF 20% 50V
C257 1-126-964-11 ELECT 10uF 20% 50V
C258 1-126-964-11 ELECT 10uF 20% 50V
C259 1-126-964-11 ELECT 10uF 20% 50V
C260 1-126-964-11 ELECT 10uF 20% 50V
C261 1-126-964-11 ELECT 10uF 20% 50V
C262 1-126-964-11 ELECT 10uF 20% 50V
C264 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
