Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
HCD-XGR90AV
The components identified by mark 0 or dotted line
with mark 0 are critical for safety.
Replace only with part number specified.
C291 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C292 1-162-974-11 CERAMIC CHIP 0.01uF 50V
< CONNECTOR >
CN201 1-766-797-11 CONNECTOR, BOARD TO BOARD 10P
CN202 1-766-797-11 CONNECTOR, BOARD TO BOARD 10P
< DIODE >
D201 8-719-988-61 DIODE 1SS355TE-17
< FILTER >
FL201 1-233-289-21 FILTER, EMI (SMD)
< IC >
IC201 8-759-571-51 IC M62464FP
< COIL>
L201 1-412-032-11 INDUCTOR CHIP 100uH
< TRANSISTOR >
Q271 8-729-141-30 TRANSISTOR 2SC3623A-LK
Q281 8-729-141-30 TRANSISTOR 2SC3623A-LK
Q291 8-729-141-30 TRANSISTOR 2SC3623A-LK
< RESISTOR >
R201 1-216-809-11 METAL CHIP 100 5% 1/16W
R202 1-216-809-11 METAL CHIP 100 5% 1/16W
R203 1-216-817-11 METAL CHIP 470 5% 1/16W
R204 1-216-851-11 METAL CHIP 330K 5% 1/16W
R205 1-216-841-11 METAL CHIP 47K 5% 1/16W
R206 1-216-847-11 METAL CHIP 150K 5% 1/16W
R207 1-218-892-11 METAL CHIP 75K 0.5% 1/10W
R208 1-216-841-11 METAL CHIP 47K 5% 1/16W
R209 1-216-847-11 METAL CHIP 150K 5% 1/16W
R210 1-218-892-11 METAL CHIP 75K 0.5% 1/10W
R211 1-216-845-11 METAL CHIP 100K 5% 1/16W
R212 1-216-845-11 METAL CHIP 100K 5% 1/16W
R213 1-216-845-11 METAL CHIP 100K 5% 1/16W
R214 1-216-845-11 METAL CHIP 100K 5% 1/16W
R216 1-216-833-11 METAL CHIP 10K 5% 1/16W
R217 1-216-833-11 METAL CHIP 10K 5% 1/16W
R271 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
R272 1-216-845-11 METAL CHIP 100K 5% 1/16W
R273 1-216-833-11 METAL CHIP 10K 5% 1/16W
R281 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
R282 1-216-845-11 METAL CHIP 100K 5% 1/16W
R283 1-216-833-11 METAL CHIP 10K 5% 1/16W
R291 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
R292 1-216-845-11 METAL CHIP 100K 5% 1/16W
R293 1-216-833-11 METAL CHIP 10K 5% 1/16W
R294 1-216-821-11 METAL CHIP 1K 5% 1/16W
******************************************************
* 1-659-058-13 SENSOR BOARD
************
< IC >
IC202 8-749-924-18 PHOTO INTERRUPTER RPI-1391
< RESISTOR >
R207 1-249-416-11 CARBON 820 5% 1/4W F
******************************************************
A-4727-612-A SUB AMP BOARD, COMPLETE
**********************
< CAPACITOR >
C101 1-126-960-11 ELECT 1uF 20% 50V
C102 1-162-292-31 CERAMIC 680PF 10% 50V
C103 1-162-286-21 CERAMIC 220PF 10% 50V
C104 1-126-967-11 ELECT 47uF 20% 50V
C105 1-136-165-00 MYLAR 0.1uF 5% 50V
C106 1-136-165-00 MYLAR 0.1uF 5% 50V
C107 1-126-968-11 ELECT 100uF 20% 50V
C108 1-136-495-11 FILM 0.068uF 5% 50V
C109 1-136-495-11 FILM 0.068uF 5% 50V
C113 1-162-306-11 CERAMIC 0.01uF 30% 16V
C114 1-162-294-31 CERAMIC 0.001uF 10% 50V
C151 1-126-960-11 ELECT 1uF 20% 50V
C152 1-162-292-31 CERAMIC 680PF 10% 50V
C153 1-162-286-21 CERAMIC 220PF 10% 50V
C154 1-126-967-11 ELECT 47uF 20% 50V
C157 1-126-968-11 ELECT 100uF 20% 50V
C158 1-136-495-11 FILM 0.068uF 5% 50V
C159 1-136-495-11 FILM 0.068uF 5% 50V
C181 1-126-960-11 ELECT 1uF 20% 50V
C182 1-162-292-31 CERAMIC 680PF 10% 50V
C183 1-162-286-21 CERAMIC 220PF 10% 50V
C184 1-126-967-11 ELECT 47uF 20% 50V
C188 1-136-495-11 FILM 0.068uF 5% 50V
C189 1-136-495-11 FILM 0.068uF 5% 50V
< CONNECTOR >
CN101 1-691-771-11 PLUG (MICRO CONNECTOR) 9P
CN102 1-691-766-11 PLUG (MICRO CONNECTOR) 4P
< DIODE >
D101 8-719-991-33 DIODE 1SS133T-77
D151 8-719-991-33 DIODE 1SS133T-77
D191 8-719-991-33 DIODE 1SS133T-77
< IC >
IC101 8-749-017-19 IC STK443-050
< TRANSISTOR >
Q101 8-729-140-84 TRANSISTOR 2SC1841-PAFAEA
Q151 8-729-140-84 TRANSISTOR 2SC1841-PAFAEA
Q181 8-729-140-84 TRANSISTOR 2SC1841-PAFAEA
< RESISTOR >
R101 1-249-417-11 CARBON 1K 5% 1/4W F
R102 1-249-437-11 CARBON 47K 5% 1/4W
R103 1-249-411-11 CARBON 330 5% 1/4W
0R107 1-212-881-11 FUSIBLE 100 5% 1/4W
0R108 1-220-755-11 METAL 0.22 10% 2W
R109 1-260-076-11 CARBON 10 5% 1/2W
