77
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
HCD-XGR90AV
TC-B
R110 1-249-437-11 CARBON 47K 5% 1/4W
R111 1-249-417-11 CARBON 1K 5% 1/4W F
R112 1-249-431-11 CARBON 15K 5% 1/4W
R113 1-249-441-11 CARBON 100K 5% 1/4W
0R120 1-217-637-00 FUSIBLE 1 5% 1/4W
0R128 1-220-755-11 METAL 0.22 10% 2W
R130 1-249-429-11 CARBON 10K 5% 1/4W
0R138 1-220-755-11 METAL 0.22 10% 2W
R151 1-249-417-11 CARBON 1K 5% 1/4W F
R152 1-249-437-11 CARBON 47K 5% 1/4W
R153 1-249-410-11 CARBON 270 5% 1/4W F
0R157 1-212-881-11 FUSIBLE 100 5% 1/4W
0R158 1-220-755-11 METAL 0.22 10% 2W
R159 1-260-076-11 CARBON 10 5% 1/2W
R160 1-249-437-11 CARBON 47K 5% 1/4W
R161 1-249-417-11 CARBON 1K 5% 1/4W F
R162 1-249-431-11 CARBON 15K 5% 1/4W
R163 1-249-441-11 CARBON 100K 5% 1/4W
0R168 1-220-755-11 METAL 0.22 10% 2W
R181 1-249-417-11 CARBON 1K 5% 1/4W F
R182 1-249-437-11 CARBON 47K 5% 1/4W
R183 1-249-411-11 CARBON 330 5% 1/4W
0R188 1-220-755-11 METAL 0.22 10% 2W
R189 1-260-076-11 CARBON 10 5% 1/2W
R190 1-249-437-11 CARBON 47K 5% 1/4W
R191 1-249-417-11 CARBON 1K 5% 1/4W F
R192 1-249-431-11 CARBON 15K 5% 1/4W
R193 1-249-441-11 CARBON 100K 5% 1/4W
******************************************************
1-683-445-11 SUB TRANS BOARD
***************
< CAPACITOR >
0C901 1-113-925-11 CERAMIC 0.01uF 20% 250V
< CONNECTOR >
CN901 1-564-321-00 PIN, CONNECTOR 2P
* CN902 1-564-321-21 PIN, CONNECTOR 2P (AUS)
CN902 1-568-106-11 PIN, CONNECTOR 4P (E)
< DIODE >
D901 8-719-991-33 DIODE 1SS133T-77
< RELAY >
0RY901 1-755-276-11 RELAY, POWER
< SWITCH >
0S901 1-786-055-21 SELECTOR, VOLTAGE (VOLTAGE SELECTOR)(E)
< TRANSFORMER >
0T901 1-437-331-11 TRANSFORMER, POWER
******************************************************
1-683-448-11 TC-A BOARD
*********
< DIODE >
D805 8-719-058-03 DIODE SEL5423E-TP15 (G)
D806 8-719-058-03 DIODE SEL5423E-TP15 (g)
< RESISTOR >
R813 1-247-843-11 CARBON 3.3K 5% 1/4W
R814 1-249-425-11 CARBON 4.7K 5% 1/4W F
R815 1-249-427-11 CARBON 6.8K 5% 1/4W F
R816 1-249-429-11 CARBON 10K 5% 1/4W
R817 1-249-431-11 CARBON 15K 5% 1/4W
R819 1-247-791-91 CARBON 22 5% 1/4W
R820 1-247-791-91 CARBON 22 5% 1/4W
< VARIABLE RESISTOR >
RV801 1-225-739-11 RES, VAR CARBON 50K (GUITAR LEVEL)
RV802 1-225-739-11 RES, VAR CARBON 50K (MIC LEVEL)
< SWITCH >
S810 1-762-875-21 SWITCH, KEYBOARD (G)
S811 1-762-875-21 SWITCH, KEYBOARD (g)
S812 1-762-875-21 SWITCH, KEYBOARD (x)
S813 1-762-875-21 SWITCH, KEYBOARD (.m)
S814 1-762-875-21 SWITCH, KEYBOARD (M>)
S815 1-762-875-21 SWITCH, KEYBOARD (DIRECTION)
******************************************************
1-683-449-11 TC-B BOARD
*********
< DIODE >
D801 8-719-058-03 DIODE SEL5423E-TP15 (g)
D802 8-719-058-03 DIODE SEL5423E-TP15 (G)
D803 8-719-057-97 DIODE SEL5923A-TP15 (X)
D804 8-719-058-04 DIODE SEL5223S-TP15 (z REC)
< RESISTOR >
R801 1-247-843-11 CARBON 3.3K 5% 1/4W
R802 1-249-425-11 CARBON 4.7K 5% 1/4W F
R803 1-249-427-11 CARBON 6.8K 5% 1/4W F
R804 1-249-429-11 CARBON 10K 5% 1/4W
R805 1-249-431-11 CARBON 15K 5% 1/4W
R806 1-249-433-11 CARBON 22K 5% 1/4W
R807 1-249-435-11 CARBON 33K 5% 1/4W
R808 1-249-439-11 CARBON 68K 5% 1/4W
R809 1-247-791-91 CARBON 22 5% 1/4W
R810 1-247-791-91 CARBON 22 5% 1/4W
R811 1-247-791-91 CARBON 22 5% 1/4W
R812 1-249-401-11 CARBON 47 5% 1/4W F
< SWITCH >
S801 1-762-875-21 SWITCH, KEYBOARD (g)
S802 1-762-875-21 SWITCH, KEYBOARD (G)
S803 1-762-875-21 SWITCH, KEYBOARD (x)
S804 1-762-875-21 SWITCH, KEYBOARD (.m)
S805 1-762-875-21 SWITCH, KEYBOARD (M>)
S806 1-762-875-21 SWITCH, KEYBOARD (z REC)
S807 1-762-875-21 SWITCH, KEYBOARD (X)
S808 1-762-875-21 SWITCH, KEYBOARD (H SPEED DUB)
S809 1-762-875-21 SWITCH, KEYBOARD (CD SYNC)
******************************************************
The components identified by mark 0 or dotted line
with mark 0 are critical for safety.
Replace only with part number specified.
