Sony HDC2400 - Connection Example 2 (HDC2550)

10
Overview
Connection example 2 (HDC2550)
Zoom Lens
(for ENG/EFP)
VCT-14
Tripod
Attachment
Tripod
HDLA1500-series
Large Lens Adaptor
HDVF-550/C730W/C550W
a)
/EL75
Viewfinder
BKW-401 Viewfinder
Rotation Bracket
HDVF-20A
HDVF-200
HDVF-C30WR
HDVF-C35W
a)
Viewfinder
HDC2550
Triax Cable
b)
CAC-6
Return Video Selector
Intercom Headset
CAC-12
Microphone
holder
Microphone
HDVF-EL70/700A
Viewfinder
HDC2550
CAC-6
Return Video Selector
Intercom Headset
Microphone
BKP-7911 Script Holder
HKCU1001
HKCU1003
HKCU2007
HDCU2000 HD Camera
Control Unit
HKCU1001
HKCU1003
HKCU2007
Camera hangers
c)
a) The HDVF-550/C730W/C550W and HDVF-C35W function as
monochrome viewfinders when monitoring a return video with the
HDC2550.
b) The maximum Triax cable length between the HDC2550 and the
HDFX100 depends on the type of cable.
For details, refer to the Operation Manual of the HDFX100.
c) Supplied with HDLA1500-series Large Lens Adaptor
Part number: A-1128-405-A
Optical Fiber
Cable
Triax cable
b)
Zoom Lens
(for studio use)
HDFX100
HD Triax
CCU Adaptor
USB drive
LAN cable
MSU-1000-series
Master Setup Unit
HDCU2500
Camera Control Unit
Video Router
Monitor
Waveform
Monitor
BNC
Hub
LAN cable
CCA-5
RCP-1000-series
Remote Control Panel
USB drive
CCA-5
BNC
RCP-1000-series
Remote Control Panel
