Menu List
DIAGNOSIS menu
OPERATION Menu
OPTICAL LEVEL
(HDC2500/2400)
D01
BOARD STATUS
D02
ROM VERSION
D03 (U15)
SERIAL No.
D04
POWER SUPPLY STATUS
D05
CCU
t
CAM
CAM
t
CCU
OHB
DPR
SY
PS
TR
(
HDC2550
)
SDI
(
HDC2500/2400
)
CAMERA APP
O.S
PANEL
HKCT
TG
SY
DPR1
DPR2
SDI
(
HDC2500/2400
)
TR
(
HDC2550
)
MODEL
NO.
OPTION
VOLTAGE
CCU OUTPUT
CAM INPUT
CAMERA CABLE
RESISTANCE
LENGTH
TEMPERATURE
CCU SUPPLY
CAM CONSUMPTION
POWER CONSUMPTION
CABLE LENGTH
OPERATION
Page title
PageNo.
Item Settings Description
<VF DISPLAY>
01 (U04)
EX ON
, OFF
ZOOM ON, OFF
DISP LEFT, RIGT
FOCUS ON, OFF
Valid only when a serial lens is used.
ND ON
, OFF
CC ON
, OFF Valid with HDC2500/2550 only.
5600K ON
, OFF
IRIS ON
, OFF
WHITE ON, OFF
D.EXT ON, OFF
OPAC ON
, OFF
GAIN ON
, OFF
SHUTTER ON
, OFF
BATT ON, OFF
RETURN ON, OFF
TALK ON
, OFF
MESSAGE ALL
, WRN, AT, OFF ALL: Displays all messages.
WRN: Displays warning messages and higher.
AT: Displays Auto Setup information and higher.
