Sony HDC2400 - DIAGNOSIS Menu

59
Menu List
DIAGNOSIS Menu
This menu is only for viewing and camera settings cannot be
made using this menu.
However, some items set the conditions for viewing.
DIAGNOSIS
Page title
PageNo.
Item Indication Description
<OPTICAL LEVEL>
(HDC2500/2400)
D01
CCU→CAM GREEN, YELLOW, RED, NG, NO SIGNAL Displayed only when a CCU is connected.
CAM→CCU GREEN, YELLOW, RED, NG, NO SIGNAL Displayed only when a CCU is connected.
CABLE LENGTH 0.0 km to 9.9 km, -.- km
Displays the camera cable length. (Applies
only to HDC2500/2400 not used with HDFX/
HDTX. Displayed only when a CCU is
connected.)
<BOARD STATUS>
D02
OHB OK, NG
DPR OK, NG
SY OK, NG
PS OK, NG
SDI OK, NG HDC2500/2400 only
TR OK, NG HDC2550 only
<ROM VERSION>
D03 (U15)
CAMERA APP Vx.xx
O.S Vx.xx
PANEL Vx.xx Displayed only when HDLA is attached.
HKCT Vx.xx Displayed only when HKC-T1500 is
installed.
TG Vx.xx
SY Vx.xx
DPR1 Vx.xx
DPR2 Vx.xx
SDI Vx.xx HDC2500/2400 only
TR Vx.xx HDC2550 only
<SERIAL No.>
D04
MODEL HDCxxxx
NO. xxxxxxx
OPTION Displayed if any option is installed.
