Sony HDC2400 - DIAGNOSIS Menu - Power and Cable; Power Supply Status Details; Camera Cable and Resistance

60
Menu List
<POWER SUPPLY
STATUS>
D05
Note
This display has a
margin of error for the
display of the electric
supply state of a
camera. Use only as a
guide.
VOLTAGE
CCU OUTPUT 100 - 250
- 300 V AC Sets the supply voltage from a CCU.
(Applies only to HDC2500/2400 not used
with HDFX/HDTX. Displayed only when a
large CCU is connected.)
Note
Set in the following way, depending on your
environment.
1. Detach all peripheral devices from your
camera.
2. Connect your camera to the CCU with the
shortest possible camera cable.
3. Input the voltage value displayed in CAM
INPUT.
(183 V) DC Displays the supply voltage for a CCU.
(Applies only to HDC2550 and other
cameras using HDFX/HDTX. Displayed only
when a portable CCU is connected.)
CAM INPUT xxx.x V Displays the input supply voltage for a
camera. (Displayed only when a CCU is
connected.)
CAMERA CABLE Applies only to HDC2500/2400 not used
with HDFX/HDTX.
RESISTANCE 0.1 - 3.4
- 9.9 ohm/100 m Sets the resistance value of each power
supply cable. (Displayed only when a CCU
is connected.)
Note
In optical fiber cable standards (2SM-9.2-
37.5/2SM-16-37.5), power source wire
impedance is specified as 3.75 ohms/100 m
at normal temperature.
However, calculations for this menu refer to
3.4 ohms/100 m at normal temperature for
an actual measurement.
Since the impedance of a power cable
differs according to the cable type, set the
power source cable impedance of a cycle
according to the optical fiber cable the you
use.
LENGTH x.x km Displays the cable length that a CCU
measured. (Displayed only when a CCU is
connected.)
TEMPERATURE LOW (-5degC), NORM (25degC)
, HIGH
(55degC)
Sets the environmental temperature for
laying a cable when performing cable
resistance compensation. (Displayed only
when a CCU is connected.)
CCU SUPPLY x.x A Displays the supply current for a CCU.
(Applies only to HDC2500/2400 not used
with HDFX/HDTX. Displayed only when a
CCU is connected.)
Note
If the camera cable is too short, an accurate
measurement is not made.
CAM CONSUMPTION xx.x A Displays camera current consumption.
POWER CONSUMPTION xxx % Displays the rate of the supply capacity
consumption.
DIAGNOSIS
Page title
PageNo.
Item Indication Description
