Setting the Camera Outputs
Constantly outputting a return video
• When a camera control unit is connected, one of the signals
being supplied to the camera control unit can be output from
the camera.
• The last selected return signal is output.
• The same textual information as that displayed on the
viewfinder screen can be added to the output signal by
setting CHARACTER to “ON” on the <SDI OUT> or <TEST
OUT> page.
To output as HD-SDI
To output as SD-SDI
To output as VBS
Outputting the same image as that on the
viewfinder screen
• With HD-SDI, you can obtain a signal that includes the same
information as that being displayed on the viewfinder screen
according to the settings of the VF MARKER,
CHARACTER, VF DETAIL, ZEBRA, etc. The ON/OFF or
other settings for adding information are common to those
for the viewfinder. The output is synchronized with switching
among Y, R, G, and B or switching to a return signal.
• With SD-SDI or VBS, the output is synchronized only with
switching between a return signal and the camera image. It
does not correspond to switching among Y, R, G, and B.
Information other than CHARACTER (such as VF
MARKER, VF DETAIL, ZEBRA) cannot be added to the
output.
Note
With the settings for outputting the same image as that on the
viewfinder screen, the output will be obtained in 1080i, even if
the format setting is 720P.
To output as HD-SDI
To output as SD-SDI
To output as VBS
Outputting via 3G-SDI (HDC2500/2400)
The SDI-1 output becomes 3G-SDI output.
To output in 1080/59.94P or 1080/50P
Outputting via Dual Link (HDC2500/2400)
The SDI-1 output is assigned to Link A, SDI-2 output to Link B.
To output in 1080/59.94P or 1080/50P
Note
Installing HZC-PRV20 software for progressive support may
be necessary.
Menu page Item Setting
<SDI OUT> SDI-MONI OUT RET
Menu page Item Setting
<SDI OUT> SDI-MONI OUT SD-SDI
DOWN CONVERTER
SELECT
RET
Menu page Item Setting
<TEST OUT> OUTPUT VBS
DOWN CONVERTER
SELECT
RET
Menu page Item Setting
<SDI OUT> SDI-MONI OUT VF
Menu page Item Setting
<SDI OUT> SDI-MONI OUT SD-SDI
DOWN CONVERTER
SELECT
VF
Menu page Item Setting
<TEST OUT> OUTPUT VBS
DOWN CONVERTER
SELECT
VF
Menu page Item Setting
<OUTPUT FORMAT> ACTIVE LINE 1080
(Format) 59.94P or 50P
<SDI OUT> SDI-1 OUT 3G-SDI
Menu page Item Setting
<OUTPUT FORMAT> ACTIVE LINE 1080
(Format) 59.94P or 50P
<SDI OUT> SDI-1 OUT MAIN/LINK-A
SDI-2 OUT/IN MAIN/LINK-B
