25
Status Display
FLR: Flare balance R/G/B/Master value
DTL: Detail level
Page 3
The setting status for CCU SD signals is displayed.
SD Matrix: Linear matrix correction for down converter output
setting
SD Detail: Contour correction function for down converter
output setting
Note
Items with no explanation are the same as those listed under
“Page 1” in ““Camera settings”” above.
System status
The model name of the camera connected to the unit, the
format setting, CCU output format setting, external reference
setting and return signal format setting are displayed.
Ref: Reference signal format and lock status
Camera: Model name of the connected camera
HD Main: Return signal format
HD Conv: HD up convert setting status
SD Conv: SD up convert setting status
RET1: Return 1 return format selection status
RET2: Return 2 return format selection status
RET3: Return 3 return format selection status
RET4: Return 4 return format selection status
CCU hardware diagnostics
The name of the board connected to the unit’s front panel and
that board’s self-diagnostic results are displayed.
HDCU 2000
Slot A to D
Slot 1 to 6
HDCU2500
Slot A to C
Slot 1 to 3
Camera system diagnostics
Page 1
CAMERA: Camera light sensor level
CCU: CCU light sensor level
Fan Power: CCU power supply fan status
Timer: Elapsed time since power-on
CCU Power: CCU power supply type and status
Fiber Cable: Cable length
SerialNo: CCU serial number
Page 2
CAMERA Cable: Camera cable connection status
CAMERA Data: Camera data transmission status
CAMERA Power: Camera power supply status
RCP/CNU Cable: This unit’s REMOTE connector cable
connection status
RCP/CNU Data: Data transmission status from a device
connected to this unit’s REMOTE connector
RCP/CNU Power: Power supply status to a device connected
to this unit’s REMOTE connector
SD Matrix: ON
CC Reduction: ON
SD Detail: ON
Level : 0 Comb : 0
Limit : 0 Lim-w : 0
Crisp : 0 Lim-b : 0
LDKnee: 0 LDGain: 0
Ratio : 0
Freq : 0
Coring: 0 Level : 35
*System Status* 1/20
Ref:HD Lock
Camera :HDC2500(HB)
HD Main:1080/59.94I
HD Conv:-------------
SD Conv:525/59.94I
RET1:1080/59.94I(PsF)
RET2:1080/59.94I(PsF)
RET3:1080/59.94I(PsF)
RET4:1080/59.94I(PsF)
1080/59.94I
** Diagnosis **
A:AT :OK 2:DRX OK
B:AVP :OK 3:DRX OK
C:DTX :OK 4:RC OK
D: 5:EN1-A OK
1:DRX :OK 6:EN2-B OK
2/20
*System Diag 1/3* 3/20
Optical Condition
CAMERA OK
CCU OK
Fan Power OK
Timer 56H
CCU Power AC OK
Fiber Cable 100m
SerialNo 00002002
*System Diag 2/3* 4/20
CAMERA Cable Connect
Data OK
Power OK
RCP/CNU Cable Connect
Data OK
Power OK
