26
Status Display
Page 3
Intercom CCU: CCU intercom selection status
Intercom MIC CAMERA ENG: Status for the camera
microphone of the ENG line
(When 1CH is selected via the INTERCOM menu (C07),
---- is displayed.)
Intercom MIC CAMERA PROD: Status for the camera
microphone of the PROD line
CAM MIC Gain: Camera microphone circuit control status
CAM MIC CH1: Camera microphone circuit 1 amp gain status
CAM MIC CH2: Camera microphone circuit 2 amp gain status
Network diagnostics
Page 1
MacAddress: CCU MAC address
Auto Negotiation: Auto negotiation setting status
Auto MDIX: Auto-MDIX setting status
Connect Speed: Connection speed setting status
Duplex Mode: Communication method setting status
MDI/MDIX Select: Communications port wiring configuration
selection status
Link Status: LAN connection status
Page 2
CNS Mode: REMOTE and LAN connectors mode setting
status
CCU No.: CCU number setting status
Master IP Address: Master device IP address
Page 3
IP Addr: CCU IP address setting status
NetMask: CCU subnet mask setting status
Def GW: CCU default gateway setting status
CCU AT board diagnostics
System Frequency: System frequency
CAM Format Setting: Camera format setting status
Reference: Reference signal setting status
Line Delay: HD-SD delay setting status
Power Supply: Status of power supply to the AT board
PLD Version: AT board PLD version
VIF Power: Status of power supply to the VIF board
CCU AVP board diagnostics
Front Power: Status of power supply to the AVP board
PLD Version: AVP board PLD version
ADO Power: Status of power supply to the ADO board
*System Diag 3/3* 5/20
Intercom
CCU System
Intercom MIC
CAMERA ENG ON
PROD OFF
CAM MIC Gain Local
dB
CH1 60
dB
CH2 60
*Network Diag 1/3* 6/20
MacAddress 00014A-xxxxxx
Auto Negotiation: ON
Auto MDIX : ON
Connect Speed : 100M
MDI/MDIX Select : MDIX
Duplex Mode : FULL
Link Status :OK
*Network Diag 2/3* 7/20
CNS Mode : MCS
Master IP Address
192.168. 0.100
CCU No. : (1)
*Network Diag 3/3* 8/20
IP Addr :192.168. 0.101
NetMask :255.255.255. 0
Def GW :192.168. 0.254
*AT Diag* 9/20
System Frequency:1.001
1080/59.94P
Reference :HD Remote
CAM Format Setting
Line Delay :Line(90H)
Power Supply:OK
PLD Version :4.00 Done
VIF Power :OK
*AVP Diag* 10/20
Front Power:OK
PLD Version:1.00 Done
ADO Power :OK
