Sony HDCU2000 - SYSTEM OPERATION Menu List: Output Format

36
Setup Menu
* Use the charts on the following as an example of how to configure these settings. The settings differ depending on the boards
connected to the expansion slots.
<OUTPUT FORMAT>
S04
CAMERA TRANSMIT When FREQUENCY HD is set to
1.001: 1080/59.94I
, 1080/
29.97PsF, 1080/59.94P, 1080/
23.98PsF, 720/59.94P, 1080/59.94I
(RGB444), 1080/29.97PsF
(RGB444), 1080/23.98PsF
(RGB444), 1080/59I (2×), 720/59P
(2×)
When FREQUENCY HD is set to
1.000: 1080/50I, 1080/25PsF,
1080/50P, 1080/24PsF, 720/50P,
1080/50I (RGB444), 1080/25PsF
(RGB444), 1080/24PsF (RGB444),
1080/50I (2×), 720/50P (2×)
Selects the output format.
This setting works in conjunction with CAMERA
FORMAT.
SLOT1 (board name)
1&2 Output format* Selects the output format for expansion slot 1’s SDI
OUT1/2 connector.
3&4 Output format* Selects the output format for expansion slot 1’s SDI
OUT3/4 connector.
SLOT2 (board name)
1&2 Output format* Selects the output format for expansion slot 2’s SDI
OUT1/2 connector.
3&4 Output format* Selects the output format for expansion slot 2’s SDI
OUT3/4 connector.
SLOT3 (board name) Output format* Selects the output format for expansion slot 3’s SDI
OUT connector.
SLOT4 (board name) Output format* Selects the output format for expansion slot 4’s SDI
OUT connector. (HDCU2000 only)
SLOT5 (board name) Output format* Selects the output format for expansion slot 5’s SDI
OUT connector. (HDCU2000 only)
SLOT6 (board name) Output format* Selects the output format for expansion slot 6’s SDI
OUT connector. (HDCU2000 only)
1080/59.94I 1080/29.97PsF 1080/59.94P 1080/23.98PsF 720/59.94P
Slot1 1&2 1080/59.94I 1080/29.97PsF 1080/59.94P
(3G)
1080/23.98PsF 720/59.94P
Slot1 3&4 M1080/59.94I M1080/29.97PsF 1080/59.94P
(3G)
M1080/23.98PsF M720/59.94P
Slot2 1&2 1080/59.94I 1080/29.97PsF 1080/59.94P
(A)
1080/59.94I 720/59.94P
Slot2 3&4 M1080/59.94I M1080/29.97PsF C1080/59.94I
(B)
M1080/59.94I M720/59.94P
Slot3 1&2 525/59.94I 525/29.97PsF 1080/59.94I 525/59.94I 525/59.94I
Slot3 3&4 M525/59.94I M525/29.97PsF M525/59.94I M525/59.94I M525/59.94I
Slot4 NTSC NTSC NTSC NTSC NTSC
