Sony HDCU2000 - SYSTEM OPERATION Menu List: Return Setup; SYSTEM OPERATION Menu List: CCU Video and 3 D Settings

40
Setup Menu
SYSTEM OPERATION
Page name
Page No.
Item Settings Description
<RETURN SETUP>
S07
FRAME SYNCHRO OFF, ON
Set the FRAME SYNCHRO function for the return
signal to on/off.
SD-RETURN
MATRIX OFF, ON
Turn the HD matrix to the SD return signal on/off.
LB LINE 360, 364
Set the effective line setting for letterbox.
ASPECT MANUAL
, AUTO Sets the auto-linking function for this unit’s aspect
setting.
RETURN-TO-RETURN
MODE NORMAL
, SMOOTH “SMOOTH” is available when the return signal is HD-
SDI.
<CCU VIDEO>
S08
VBS-CHROMA OFF, ON
Turns the VBS output signal’s cross signal on/off.
MONO-COLOR OFF
, ON Sets the MONO COLOR function on/off.
PHASE 0 to 358, 0
Adjusts the color phase for the MONO COLOR
function.
SATURATION –99 to 99, 0
Adjusts the color saturation for the MONO COLOR
function.
<3D SETTINGS>
S09
3D MODE OFF
, ON Turns the 3D Mode setting ON/OFF. (Available only
with the HDFA-200 expansion.)
3D OUTPUT 3D MONITOR
, RIGHT ONLY,
LEFT ONLY
Sets 3D Monitor output.
3D MONITOR SPLIT SCREEN
, SIDE BY SIDE,
ANAGLYPH, 50% MIX,
DIFFERENCE, DIFF Y ONLY,
MIRROR, CROP SPLIT, V SPLIT,
CHECKER BOARD, LINE BY LINE
Displays the format.
POSITION –99 to 99, 0
Sets the WIPE division ratio and MIX mix ratio.
(Displayed when 3D MODE is set to ON.)
MIX CHROMA ON
, OFF Selects whether to display chroma information when
MIX is activated.
DIFF MODE L-R
, R-L Switches to the difference image calculation
operation.
V SPLIT MODE L/R
, R/L Switches the left and right sides when splitting the
display.
BORDER LINE OFF
, ON Selects whether or not to display the boundary line
when splitting the display.
CHANNEL ID (OFF), (ON) Selects whether to display the Channel ID with this
line’s output.
