Setup Menu
CCU CONFIGURATION menu
CCU
CONFIGURATION
Page name
Page No.
Item Settings Description
<COLOR BAR>
C01
HD-BAR
SEL BAR 16:9 (100%)
, BAR 16:9
(75%), SMPTE 16:9 (BLACK),
SMPTE 16:9 (–I/Q), BAR 4:3
(100%), BAR 4:3 (75%), SMPTE
4:3 (BLACK), SMPTE 4:3 (–I/Q),
MF-ARIB (75%), MF-ARIB (100%),
MF-ARIB (+I), MF-SMPTE (–I,Q),
MF-SMPTE (75%,Q), MF-SMPTE
(100%,Q), MF-SMPTE (+I,Q), HD-
CUSTOM, SDI CHECK FIELD, Y-
RAMP, Y/C-RAMP, HD-CUSTOM2
Sets an HD output color bar.
MF CB MODIFY
, EVEN Sets a multi-format color bar.
SLOPE WIDE
, NARROW Sets the chroma band for a color bar.
SD-BAR For NTSC: SMPTE
, EIA, FULL,
95%, NTSC100%, Y/C-RAMP, Y-
RAMP
For PAL: SMPTE
, EIA, EBU, 95%,
PAL100%, Y/C-RAMP, Y-RAMP
Sets SD output for a color bar.
DSB, ENB
DSB: Down convert and display the HD color bar.
ENB: Display the set SD color bar.
BAR-CHARA ON, OFF
Turns the signal for characters superimposed on a
color bar ON/OFF.
GRAY ON
, OFF ON: Gray screen output when camera power supply
is off.
OFF: Color bar signal output when camera power
supply is off.
MOVING SYMBOL ON, OFF
Turns the moving symbol superimposed on the color
bar ON/OFF.
TYPE 0
, 1, 2 Sets the symbol type.
SIZE SMALL
, LARGE Sets the symbol size.
<BAR CHARACTER>
C02
BAR CHARACTER Sets strings 1 to 12 that are superimposed on the
color bar signal.
ALL CLEAR Execute to clear all character strings. (Execute via
ENTER.)
<MONITOR 1>
C03
CHARACTER Sets the MONITOR output bar character.
WHITE-LEVEL 0.0 to 107.0% 71.5
Sets the MONITOR output bar character level.
BLACK-LEVEL 0.0
to 107.0% Sets the MONITOR output bar character border
black level.
PIX CHARACTER Sets the PIX output bar character. (Displayed only
when HKCU1001/1003 is installed.)
WHITE-LEVEL 0.0 to 107.0%, 75.0
Sets the PIX output bar character level.
BLACK-LEVEL 0.0
to 107.0% Sets the PIX output bar character border black level.
