Setup Menu
NETWORK SETTINGS menu
<TRANSMIT>
C20
TRANSMIT AUTO, HIGH BIT RATE, HD-SDI,
(HD-SDI)
Sets the optical transmission rate between a camera
and CCU.
CABLE CAMERA CABLE
, COAX Sets the transmission method between a camera
and CCU.
TRIAX ADAPTER
TYPE DISABLE
, A-TRIAX, D-TRIAX Sets the TRIAX adapter type.
MODE AUTO TRIAX, FIBER Sets the transmission method of the TRIAX adapter.
<SPIRIT LEVEL>
C21
(Available only when a
serial lens is attached to
the HDC2000/2500 series
HD Color Camera.)
INDICATOR OFF
, ON, --- Turns the spirit level display on/off.
REVERSE OFF
, ON OFF: Moves to the tilted direction.
ON: Moves to the reverse direction of the tilted
direction.
H POSITION 0 to 99, 50
Adjusts the horizontal position.
V POSITION 0 to 99, 50
Adjusts the vertical position.
<BOARD SETUP>
C22
BOARD SELECT DRX1
, DRX2, DRX3, DRX4, RC Selects the board to set.
EMBED AUDIO ON
, OFF Sets superimposition of audio data to ON/OFF.
META DATA EMB OFF
, ON Sets superimposition of metadata to ON/OFF.
PAYLOAD ID LATEST
, 2002, 2010, 2011 Sets the PAYLOAD ID of VIDEO.
INTER LOCK OFF
, ON SDI output (3, 4) format linking function
<OTHERS>
C23
ASSIGNABLE NONE
, BARS, CLEAN, CAM
POWER, FORCE LEGACY, REF
LOCAL HD, REF LOCAL SD
Sets the function for the assignable button.
NONE: No assignment.
BARS: Sets the color bar output to ON/OFF.
CLEAN: Sets character superimposition for all
output slots to ON/OFF.
CAM POWER: Sets camera power to ON/OFF.
FORCE LEGACY: Forces the communication mode
to LEGACY mode.
REF LOCAL HD: Sets GENLOCK to LOCAL HD.
REF LOCAL SD: Sets GENLOCK to LOCAL SD.
CCU NO 0
, 0 to 96, A to Z Sets the CCU number.
SYNC OUT SD SYNC
, HD SYNC Sets the SYNC OUT connector.
REF 10F BB OFF
, ON Sets the 10F BB function.
CAM MENU OFF
, ON Displays the Camera menu.
• If CAM MENU is set to ON, CCU
CONFIGURATION menu operations cannot be
performed because only Camera menu operations
are available.
• The Camera menu is not displayed when SD
signal is output.
NETWORK SETTINGS
Page name
Page No.
Item Settings Description
<IP ADDR SET>
N01
HOST IP ADDRESS 0.0.0.0
to 255.255.255.255 Displays the IP address.
SUB NET MASK 0.0.0.0
to 255.255.255.254 Displays the subnet mask.
DEFAULT GATEWAY 0.0.0.0
to 255.255.255.255 Displays the default gateway.
SET A “SET OK?” message is displayed. Press ENTER
again to confirm the change. (Execute via ENTER.)
