Sony HDCU2000 - CCU CONFIGURATION: Menu Settings and Display Options; CCU CONFIGURATION: Date, Tally, and Alarm Settings

45
Setup Menu
<MENU SETTINGS>
C15
RESUME ON, OFF Turns ON/OFF the menu mode resume page display
function.
ALARM JUMP ON, OFF
Turns ON/OFF the error-related page display
function for when an error occurs while in menu
mode.
RE DIRECTION CONTROL knob operating mode settings
CATEGORY STD
, RVS STD: CONTROL knob clockwise rotation moves the
CCU MENU pointer (,) down.
RVS: CONTROL knob counterclockwise rotation
moves the CCU MENU pointer (,) down.
PAGE STD
, RVS STD: CONTROL knob clockwise rotation displays
the next page in the menu.
RVS: CONTROL knob counterclockwise rotation
displays the next page in the menu.
ITEM STD
, RVS STD: CONTROL knob clockwise rotation moves the
pointer (,) down to the next item on the page.
RVS: CONTROL knob counterclockwise rotation
moves the pointer (,) down to the next item on the
page.
DATA STD
, RVS STD: CONTROL knob clockwise rotation selects the
next data option.
RVS: CONTROL knob counterclockwise rotation
selects the next data option.
<DISPLAY>
C16
Turn camera messages
and switch settings ON/
OFF for the camera’s
diagnostics screen.
MESSAGE ALL
, WARNING, OFF ALL: Displays all messages.
WARNING: Displays system warning messages and
menu control messages.
OFF: Displays only menu control messages.
MASTER GAIN ON
, OFF Displays or hides the master gain indication.
EVS/SHUTTER ON
, OFF Displays or hides the ECS/shutter indication.
ND FILTER ON
, OFF Displays or hides the ND filter indication.
CC FILTER ON
, OFF Displays or hides the CC indication.
IRIS ON
, OFF Displays or hides the IRIS indication.
EXTENDER ON
, OFF Displays or hides the EXTENDER indication.
<DATE>
C17
DATE/TIME 20YY/MM/DD hh:mm Sets the date and time.
TIME ZONE hh:mm
–11h59m to +11h59m
Sets the time zone.
<TALLY INPUT>
C18
R-TALLY CONTACT
, POWER (24V),
POWER (TTL)
RED tally input setting
G-TALLY CONTACT
, POWER (24V),
POWER (TTL)
GREEN tally input setting
Y-TALLY CONTACT
, POWER (24V),
POWER (TTL)
YELLOW tally input setting
<ALARM SETTINGS>
C19
FORCE LEGACY OFF, ON
Set to OFF to not display the FORCE LEGACY
alarm.
SUB REF NONE OFF, ON
Set to OFF to not display the REF NONE alarm.
SUB REF INVALID OFF, ON
Sets to OFF to not display the REF INVALID alarm.
CCU
CONFIGURATION
Page name
Page No.
Item Settings Description
