44
Setup Menu
<PROMPT/TRUNK 2>
C11
NETWORK TRUNK
MODE (OFF), OFF
, NETWORK,
NETWORK + VIDEO
Sets the mode for the network trunk.
RATE ---, (100Mbps), (1Gbps) Sets the rate for the network trunk line.
HD PROMPTER (ENABLE), (DISABLE) Displays “ENABLE” or “DISABLE” for HD
PROMPTER.
FRAME SYNC OFF
, ON, (ON) Turns the frame sync function ON/OFF.
HD TRUNK (ENABLE), (DISABLE) Displays “ENABLE” or “DISABLE” for HD TRUNK.
<VIDEO SETUP>
C12
SETUP ON
, OFF, --- ON: Adds a setup signal to VBS and SD YCD
component signal Ych-SYNC.
OFF: No setup signal is added.
---: Displayed when the format is PAL. (Display only)
SD BLK CLP OFF, ON
Y signals from SD SDI output that are less than 0%
are clipped at 0%.
Q FILTER WD
, NA Sets the Q filter bandwidth. (Displayed only when
HKCU1001 or HKCU1003 is installed.)
G/Y SYNC OFF
, ON Sets the R/G/B component signal’s G ch-SYNC to
on/off. (Displayed only when HKCU1001 or
HKCU1003 is installed.)
VCS RELAY OFF, ON
Sets the PIX/WFM connector output. (Displayed only
when HKCU1001 or HKCU1003 is installed.)
<VIDEO ADJUST 1>
C13
(Available when a
HKCU1001 or HKCU1003
board is installed)
VBS
LEVEL –99 to 99, 0
Adjusts the VBS output video level.
CHROMA –99 to 99, 0
PIX
LEVEL –99 to 99, 0
Adjusts the PIX output video level.
CHROMA –99 to 99, 0
WFM
LEVEL –99 to 99, 0
Adjusts the WFM output video level.
CHROMA –99 to 99, 0
<VIDEO ADJUST 2>
C14
(Available when two
HKCU1001 or HKCU1003
boards are installed)
VBS
LEVEL –99 to 99, 0
Adjusts the VBS output video level.
CHROMA –99 to 99, 0
PIX
LEVEL –99 to 99, 0
Adjusts the PIX output video level.
CHROMA –99 to 99, 0
WFM
LEVEL –99 to 99, 0
Adjusts the WFM output video level.
CHROMA –99 to 99, 0
(Available when yet
another VDA board from
the HKCU1003 is installed
to the option slot)
G/Y LEVEL –99 to 99, 0
Adjusts the G/Y output video level.
B/B-Y LEVEL –99 to 99, 0
Adjusts the B/B-Y output video level.
R/R-Y LEVEL –99 to 99, 0
Adjusts the R/R-Y output video level.
CCU
CONFIGURATION
Page name
Page No.
Item Settings Description
To Next Page
