Setup Menu
<INTERCOM>
C08
INTERCOM CH 1CH, 2CH Selects the intercom channel number.
SYSTEM INTERFACE
PRODUCER 4WIRE
, RTS, CLEAR COM Sets the producer line intercom system.
CANCEL LVL –99 to 99 0
Sets the side tone cancel level.
TERMINATION (OFF)
, ON Connects to a 200 Ω terminator, if ON is selected
while 2-wire intercom interface (RTS or CLEAR
COM) is used.
(OFF): Displayed when 4WIRE is selected in
SYSTEM I/F. (Display only)
ENGINEER 4WIRE
, RTS, CLEAR COM Sets the engineer line intercom system.
CANCEL LVL –99 to 99 0
Sets the side tone cancel level.
TERMINATION (OFF)
, ON Connects to a 200 Ω terminator, if ON is selected
while 2-wire intercom interface (RTS or CLEAR
COM) is used.
(OFF): Displayed when 4WIRE is selected in
SYSTEM I/F. (Display only)
PGM1 INPUT –20, 0
, +4 dBu Sets the PGM1 input level.
PGM2 INPUT –20, 0
, +4 dBu Sets the PGM2 input level.
<FRONT INCOM>
C09
(MIC ON), (MIC OFF), (PGM ON) CCU front panel MIC/PGM switch position. (Display
only)
(PROD), (ENG), (PRIVATE) CCU front panel INTERCOM switch position.
(Display only)
INCOM MIC CARBON, ECM, DYNAMIC
Sets the headset microphone connected to the
INTERCOM connector on the front panel.
CARBON: Carbon microphone (power supply, 20dB
gain)
ECM: Electret condenser microphone (power
supply, 40dB gain)
DYNAMIC: Dynamic microphone (no power supply,
60dB gain)
MIC TYPE BALANCE, UNBALANCE
Sets the headset microphone connected to the
INTERCOM connector on the front panel.
BALANCE: Balanced microphone
UNBALANCE: Unbalanced microphone
MIC GAIN –6dB, 0dB
, +6dB Sets the input gain.
SIDE TONE 0 to 99 50
Sets the side tone level.
PGM MIX OFF
, INCOM+PGM, L-INCOM/R-
PGM
OFF: Signals are not mixed.
INCOM+PGM: INCOM and PGM signals are mixed.
L-INCOM/R-PGM: Outputs an INCOM signal
through the left channel and a PGM signal through
the right.
PGM SEL PGM1
, PGM2, PGM1 + PGM2 Selects the PGM type.
PGM1 LVL 0 to 99 50
Sets the PGM1 level.
PGM2 LVL 0 to 99 50
Sets the PGM2 level.
<PROMPT/TRUNK 1>
C10
PROMPTER CH 1CH, 2CH
Sets the number of prompter lines. (HDCU2500 is
locked to 1CH.)
TRUNK LINE
CH 1CH, 2CH
Sets the number of channels to be used.
IF 232C
, 422A Sets the communication line mode.
RATE (38Kbps), (19Kbps), (75Kbps),
(150Kbps)
Displays the TRUNK line. (Display only)
AUX REMOTE DISABLE
, ENABLE Sets whether or not AUX REMOTE is used.
