Getting Started
Install the subwoofer and speakers as shown in the illustration below.
• Do not block the heat ventilation on the rear panel of the subwoofer.
• Do not cover the grill of the subwoofer.
• It is recommended to place the subwoofer on the front edge of a table or rack, etc., to accept the remote signal
correctly.
To use the speakers efficiently
Position the speakers so that the distance between each speaker and the listening position (A and B)
is the same (from 0.0 to 7.0 m).
• Place both speakers the same distance apart as they are from the listening position (to form an isosceles triangle).
• The speakers should be placed at least 0.6 m apart.
• Place the speakers forward of the TV. Make sure there are no reflecting obstacles in the way of the speakers.
Installing the system
Notes
Subwoofer
Speaker (L) Speaker (R)
Speaker (L)
TV
Speaker (R)
Subwoofer
continued
