Other Functions
2 Prepare screws (not supplied) that
are suitable for the holes on the rear
of the Bar Speaker or surround
speakers.
3 Fasten the screws in the wall.
The screw should protrude as
illustration.
For the Bar Speaker
For the surround speakers
Screw (supplied)
Wall mounting
barckets (supplied)
Hole on the rear of the speakers
4mm
More than 30 mm
Bar Speaker: 4.6 mm
Surround speakers: 5 mm
10 mm
940 mm
5 mm to
7mm
10 mm to
12 mm
