Sony HTC-VX500 - Page 35

35
5.2 Vp-p
474 ns
1.3 Vp-p
+0.25
–0.20
Approx.
500 mVp-p
Approx.
200 mVp-p
1.3 Vp-p
+0.25
–0.20
5.2 Vp-p
22.7 µ s
5.2 Vp-p
16.9344 MHz
2.6 Vp-p
7.5
µ s
5 Vp-p
22.8 µ s
4.4 Vp-p
472 ns
4.1 Vp-p
10 MHz
3.3 Vp-p
10 MHz
4.8 Vp-p
16.7 ms
• Waveforms
BD BOARD
1 IC101 wh (RFDC) 200 mV/DIV, 500 ns/DIV
2 IC101 wj (TE) 200 mV/DIV, 100 µs/DIV
3 IC101 wl (FE) 200 mV/DIV, 50 ns/DIV
4 IC101 eh (RFAC) 200 mV/DIV, 500 ns/DIV
5 IC101 rg (LRCK)
6 IC101 rj (BCLK)
7 IC101 ys (XTAI)
8 IC101 oh (MDP)
VIDEO BOARD
1 IC501 5 (LRCK)
2 IC501 qd (BCLK)
3 IC502 qd (XOUT)
4 IC502 qg (XIN)
5 IC502 rg (BUS)
