Sony HTC-VX500 - Page 36

36
3.4 Vp-p
8.1 MHz
4.2 Vp-p
8.1 MHz
4.8 Vp-p
472 ns
4.8 Vp-p
22.8 µ s
1.7 Vp-p
H
5.2 Vp-p
60 ns
3.1 Vp-p
16.7 ms
4.3 Vp-p
8.7 ms
6 Vp-p
22.6 µ s
4.8 Vp-p
472 ns
1.8 Vp-p
H
1 Vp-p
H
0.9 Vp-p
H
4.9 Vp-p
37 ns
0.5 Vp-p
H
qa IC505 ug (C-OUT)6 IC402 ql (XIN)
7 IC402 w; (XOUT)
8 IC505 3 (CD-BCK)
9 IC505 5 (CD-LRCK)
0 IC505 yl (Y-OUT)
qs IC505 ih (DA-XCLK)
qd IC505 od (PGIO2/VSYNK/CSYNK)
qf IC505 <z/n (VCK-IN)
qg IC505 <z/, (DA-LRCK), IC509 ql (LRCK)
qh IC505 <zzz (DA-BCK), IC509 !¶ (BCK)
qj Q301 (Base)
qk Q303, 304 (Base)
ql Q308 (Base)
w; IC509 4 (MCKO)
