SECTION 2
GENERAL
Front Panel
LOCATION OF PARTS AND CONTROLS
1 DISC SKIP/EX-CHANGE button
2 DISC 1 button
3 DISC 2 button
4 DISC 3 button
5 DISC NUMBER 1` 2` 3 indicator
6 ( (CD play) indicator
7 P (CD pause) indicator
8 6 OPEN/CLOSE button
9 p (CD stop) button
10 ·P (CD play pause) button
11 œ (Deck A play) indicator
12 r (Deck B rec) indicator
13 P (Tape (Deck B pause)) indicator
14 œ (Deck B play) indicator
15 · (Deck B play) button
16 ª (Deck B play) button
17 π (Deck B stop) button
18 § (Deck B eject) button
19 Casette lid (Deck B)
20 DIRECTION MODE button
21 P PAUSE button
22 r REC button
23 HI-SPEED DUBBING button
24 CD SYNCHIRO button
25 DOLBY NR button
26 Casette lid (Deck A)
27 § EJECT (Deck A) button
28 π (Deck A stop) button
29 ª (Deck A play) button
30 · (Deck A play) button
31 CD Disc tray
1
29
30
31
28
27
192021222326 2425
1411 12 13
15
16
17
18
234 5 7 869
10
