Sony HVO-500MD Instructions For Use

38
Recording
Chapter 4 Recording and Playback
Chapter
4
Recording and Playback
Recording
Images can be recorded manually or via contact switch.
This section describes how to record manually.
For details on configuring patient information and storage
destinations for recorded data beforehand, see
“Recording Preparation” (page 43).
For details on how to record via contact switch, contact
your local Sony representative.
Note on the auto delete function for
recorded data
The function automatically deletes recorded data, starting
with recorded data on external media with the oldest start
dates for recording, whenever the remaining capacity on
the unit’s internal hard disk becomes low. This is done to
maintain free space on the unit’s internal hard disk at all
times.
Manual Recording
1 Press the z REC button.
Recording starts.
If you press the MENU button while recording is in
progress, the following screen appears.
In addition, “REC” appears on the front panel display
while recording is in progress.
Tip
zREC button
REC 00:00:10
1234567890123456
Patient ID
This appears when audio is
also being recorded.

Sony HVO-500MD Specifications

General

Display	LCD
Product color	White
LED indicators	Yes
Playback resolutions supported	1280 x 720
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	5 - 40 °C
Operating relative humidity (H-H)	20 - 80 %
HDD capacity	500 GB
BNC input ports	1
USB 2.0 ports quantity	4
Optical drive included	No

Weight and Dimensions

Weight	2900 g
Dimensions (WxDxH)	212 x 290 x 105.5 mm
