Sony HVO-500MD Instructions For Use

88
Initial User Settings
Chapter 5 System Administrator Settings
3 Configure the quality settings for still images.
Select an item using the
V and v buttons, and press the
ENTER button to display the setting screen for that
item.
[Format]
Select a format for still image files in the setting screen
that appears, and press the ENTER button.
[Quality]
This setting can be configured when [Format] is set to
[JPEG].
Select the still image quality in the setting screen that
appears, and press the ENTER button.
[Capture]
Select whether to use the frame capture or field capture
mode in the setting screen that appears, and press the
ENTER button.
[Rec Quantity] displays the following information.
• For the HVO-500MD: Estimated recording time
available for USB media (500 GB).
• For the HVO-550MD: Estimated recording time
available for single-layer DVD-R1 discs (4.7 GB).
4 When you finish configuration, use the V, v, B, and b
buttons to select [Apply], and press the ENTER
button.
The [System Admin Settings] screen appears again.
[Save] Tab
Configure settings related to external media used to store
recorded data.
1 Use the B and b buttons to select the [Save] tab.
2 Configure each setting.
Select an item using the
V and v buttons, and press the
ENTER button to display the setting screen for that
item.
Tip

Sony HVO-500MD Specifications

General

Display	LCD
Product color	White
LED indicators	Yes
Playback resolutions supported	1280 x 720
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	5 - 40 °C
Operating relative humidity (H-H)	20 - 80 %
HDD capacity	500 GB
BNC input ports	1
USB 2.0 ports quantity	4
Optical drive included	No

Weight and Dimensions

Weight	2900 g
Dimensions (WxDxH)	212 x 290 x 105.5 mm
