Sony HVO-500MD Instructions For Use

68
Function Settings
Chapter 5 System Administrator Settings
Function Settings
Configure initial settings related to recording and external
devices.
1 In the [System Admin Settings] screen, use the V, v,
B, and b buttons to select [Function Settings], and
press the ENTER button.
The [Function Settings] screen appears.
2 Use the B and b buttons to select a tab, and configure
settings as necessary.
For details on each tab, see the following.
“[General 1] Tab” (page 68)
“[General 2] Tab” (page 69)
“[Video 1] Tab” (page 73)
“[Video 2] Tab” (page 75)
3 When you finish configuration, use the V, v, B, and b
buttons to select [Apply], and press the ENTER
button.
The configurations are saved, and the [System Admin
Settings] screen appears again.
[General 1] Tab
Configure initial system settings.
1 Use the B and b buttons to select the [General 1] tab.
2 Configure each setting.
Select an item using the
V and v buttons, and press the
ENTER button to display the setting screen for that
item.
[Facility Name]
Enter the facility name (up to 32 characters) using the
on-screen keyboard.
For details on using the on-screen keyboard, see
“Using the On-Screen Keyboard” (page 29).
[Digits in Patient ID]
Select the number of digits to use for patient ID
numbers in the setting screen that appears, and press
the ENTER button.
The default setting is [8]. Between 4 to 16 digits can be
used.

Sony HVO-500MD Specifications

General

Display	LCD
Product color	White
LED indicators	Yes
Playback resolutions supported	1280 x 720
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	5 - 40 °C
Operating relative humidity (H-H)	20 - 80 %
HDD capacity	500 GB
BNC input ports	1
USB 2.0 ports quantity	4
Optical drive included	No

Weight and Dimensions

Weight	2900 g
Dimensions (WxDxH)	212 x 290 x 105.5 mm
