Index to Parts and Controls
Refer to the pages indicated in parentheses for details.
Main unit
9
q;
qa
qs
qd
qf
qg
qh
1
2
3
4
5
6
7
8
1 VOL (volume) control (14)
2 FILE button (10, 13, 18)
3 MIC (built-in microphone)
(10)
4 NxPLAY/STOP (play/
stop•enter) button (8, 14, 15)
5 –./>+ (fast forward/
fast backward•selection of
menu mode) button (13, 15)
6 STOP button (11)
7 HOLD switch (25)
8 PLAY SPEED selector (19)
9 MENU button (8, 21, 34)
0 Display window (33)
qa OPR (operation) indicator
(10, 14)
qs ERASE button (16)
qd REC (record) START/STOP
button (10)
qf Speaker
qg EAR (earphone) jack (15)
qh Hand strap (supplied to
ICD-57/67 only)
