Sony ICD-ST25 - Printed Wiring Board - MAIN Board (Side A); Ic6001

1616
ICD-ST25
4-2. PRINTED WIRING BOARD – MAIN BOARD (SIDE A) –
• : Uses unleaded solder.
IC6001
IC5003
IC5001
IC6002
IC5005
IC5002
IC6003
IC3002
IC3003
IC6004
IC3001
IC3004
J3002
i
HOLD
ON
S
S
S
S
S
S
S
S
13
45
1
1
1 45
8
E
1
14 85
Q5013
3
3 1
4
4 3
2
2
5
3
6 4
E
E
C1008
C2009
C6002
C5012
R5012
OFF
mPLUG IN POWER
J3001
MAIN BOARD
1-687-788-
13
(13)
(SIDE A)
CSP(Chip Size Package)
12
A
B
C
D
E
F
3456789
J5001
3
L
L
SW
SW
R
R
GND
GND
Ref. No. Location
D5002 C-2
D5003 D-3
D5004 D-3
D5005 D-2
D5007 E-2
D5009 E-2
IC3001 D-7
IC3002 E-7
IC3003 C-6
IC3004 D-6
IC5001 C-3
IC5002 B-2
IC5003 C-3
IC5005 B-4
IC6001 C-5
IC6002 E-5
IC6003 E-5
IC6004 F-7
• Semiconductor Location
Ref. No. Location
Q3001 D-7
Q3002 B-8
Q3004 E-8
Q5001 C-5
Q5002 D-3
Q5003 E-3
Q5005 C-1
Q5006 E-6
Q5007 E-6
Q5008 B-6
Q5009 C-1
Q5010 B-2
Q5011 C-1
Q5012 C-3
Q5013 E-2
Q5014 B-3
VDR5002 B-1
