Sony ICD-ST25 - Block Assy

8
ICD-ST25
2-6. THE CAUTIONS AT THE TIME OF A MICROPHONE BLOCK ASSY
4 pan tapping screw
(M1.4
× 2)
1 pan tapping screw
(M1.4
× 4.5)
microphone cover
microphone base
microphone base
screw hole part
microphone cushion
microphone unit
microphone case
click plate
microphone unit
flexible board
2 It inserts in a microphone base.
3 It turns in the direction of an arrow.
