Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
36
SECTION 6
ELECTRICAL PARTS LIST
ICD-ST25
NOTE:
• Due to standardization, replacements in the
parts list may be different from the parts
specified in the diagrams or the components
used on the set.
• -XX, -X mean standardized parts, so they
may have some difference from the original
one.
• Items marked “*” are not stocked since they
are seldom required for routine service.
Some delay should be anticipated when
ordering these items.
• CAPACITORS:
uF: µF
• RESISTORS
All resistors are in ohms.
METAL: metal-film resistor
METAL OXIDE: Metal Oxide-film resistor
F: nonflammable
• COILS
uH: µH
•Abbreviation
CND : Canadian model
JE : Tourist model
KR : Korea model
• SEMICONDUCTORS
In each case, u: µ, for example:
uA...: µA... , uPA... , µPA... ,
uPB... , µPB... , uPC... , µPC... ,
uPD..., µPD...
• Accessories are given in the last of this parts
list.
When indicating parts by reference number,
please include the board name.
F-SW MAIN
* A-4547-169-A F-SW BOARD, COMPLETE
*********************
< CONNECTOR >
CN901 1-816-935-21 CONNECTOR, FFC/FPC 10P
< DIODE >
D902 8-719-073-33 DIODE CL-165HR/YG-D-T (OPR)
< RESISTOR >
R903 1-208-695-11 METAL CHIP 3.3K 0.5% 1/16W
R904 1-208-699-11 METAL CHIP 4.7K 0.5% 1/16W
R912 1-218-953-11 RES-CHIP 1K 5% 1/16W
R913 1-218-961-11 RES-CHIP 4.7K 5% 1/16W
R918 1-218-981-11 RES-CHIP 220K 5% 1/16W
R919 1-218-977-11 RES-CHIP 100K 5% 1/16W
< SWITCH >
S901 1-786-436-21 SWITCH, SLIDE (DIRECTNL)
S902 1-572-922-11 SWITCH, SLIDE (DPC)
S903 1-771-844-11 SWITCH, TACTILE (SMD)
(z A-B / PRIORITY)
S904 1-771-844-11 SWITCH, TACTILE (SMD) (ERASE)
S905 1-771-844-11 SWITCH, TACTILE (SMD)
(z DIVIDE/ bookmark)
S911 1-572-922-11 SWITCH, SLIDE (VOICE UP)
************************************************************
* A-4547-174-A MAIN BOARD, COMPLETE
*********************
3-250-040-11 TERMINAL (+), BATTERY
3-250-041-11 TERMINAL (-), BATTERY
3-251-177-01 SPACER (JACK)
3-250-332-01 CAP (TERMINAL)
< CAPACITOR >
C1001 1-164-943-11 CERAMIC CHIP 0.01uF 10% 16V
C1002 1-164-943-11 CERAMIC CHIP 0.01uF 10% 16V
C1003 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C1004 1-125-891-11 CERAMIC CHIP 0.47uF 10% 10V
C1005 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C1006 1-119-923-11 CERAMIC CHIP 0.047uF 10% 10V
C1007 1-119-923-11 CERAMIC CHIP 0.047uF 10% 10V
C1008 1-119-923-11 CERAMIC CHIP 0.047uF 10% 10V
C1011 1-107-819-11 CERAMIC CHIP 0.022uF 10% 16V
C1012 1-110-569-11 TANTAL. CHIP 47uF 20% 6.3V
C1013 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C1015 1-164-937-11 CERAMIC CHIP 0.001uF 10% 50V
C1016 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C2001 1-164-943-11 CERAMIC CHIP 0.01uF 10% 16V
C2002 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C2003 1-125-891-11 CERAMIC CHIP 0.47uF 10% 10V
C2004 1-164-943-11 CERAMIC CHIP 0.01uF 10% 16V
C2005 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C2006 1-119-923-11 CERAMIC CHIP 0.047uF 10% 10V
C2007 1-119-923-11 CERAMIC CHIP 0.047uF 10% 10V
C2008 1-119-923-11 CERAMIC CHIP 0.047uF 10% 10V
C2009 1-107-819-11 CERAMIC CHIP 0.022uF 10% 16V
C2012 1-110-569-11 TANTAL. CHIP 47uF 20% 6.3V
C2013 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C2015 1-164-937-11 CERAMIC CHIP 0.001uF 10% 50V
C2016 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C3001 1-164-943-11 CERAMIC CHIP 0.01uF 10% 16V
C3003 1-117-919-11 TANTAL. CHIP 10uF 20% 6.3V
C3004 1-117-919-11 TANTAL. CHIP 10uF 20% 6.3V
C3005 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C3007 1-125-837-11 CERAMIC CHIP 1uF 10% 6.3V
C3008 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C3009 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C3010 1-125-837-11 CERAMIC CHIP 1uF 10% 6.3V
C3011 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C3012 1-117-919-11 TANTAL. CHIP 10uF 20% 6.3V
C3013 1-164-933-11 CERAMIC CHIP 220PF 10% 50V
C3015 1-125-837-11 CERAMIC CHIP 1uF 10% 6.3V
C3016 1-107-819-11 CERAMIC CHIP 0.022uF 10% 16V
C3017 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C3018 1-113-600-11 TANTAL. CHIP 2.2uF 20% 6.3V
C3019 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C3020 1-117-919-11 TANTAL. CHIP 10uF 20% 6.3V
C3021 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C3022 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C3023 1-164-943-11 CERAMIC CHIP 0.01uF 10% 16V
C3024 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C3025 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C3026 1-164-937-11 CERAMIC CHIP 0.001uF 10% 50V
C3027 1-117-919-11 TANTAL. CHIP 10uF 20% 6.3V
C3028 1-117-919-11 TANTAL. CHIP 10uF 20% 6.3V
C3030 1-125-837-11 CERAMIC CHIP 1uF 10% 6.3V
C5001 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C5003 1-137-934-11 TANTAL. CHIP 47uF 20% 10V
C5004 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C5005 1-117-919-11 TANTAL. CHIP 10uF 20% 6.3V
