Sony ICD-ST25 - Printed Wiring Board - MAIN Board (Side B)

1717
ICD-ST25
4-3. PRINTED WIRING BOARD – MAIN BOARD (SIDE B) –
• : Uses unleaded solder.
Ref. No. Location
D7002 C-9
D7003 E-9
D7004 C-8
D8001 F-3
D8002 E-2
IC7001 E-3
IC7002 E-5
IC7003 D-7
IC7004 C-8
IC7005 E-8
IC8001 D-2
IC8003 F-3
Q3003 E-9
Q7001 D-3
Q7002 D-3
Q7003 D-8
Q7004 E-8
Q7005 E-8
• Semiconductor
Location
IC8001
IC8003
IC7001
IC7002
IC7003
IC7004
IC7005
MAIN BOARD
1-687-788-
13
(13)
(SIDE B)
12
A
B
C
D
E
F
3456789
DRY BATTERY
SIZE "AAA"
(IEC DESIGNATION LR 03)
2PCS,3V
SP3001
(SPEAKER)
1
1
S
S
R7011
181
1
2
136
3
E
E
S
(LCD PANEL LIGHT)
(LCD PANEL LIGHT)
1
1
5
2
4
4
2
3
1
MICROPHONE
UNIT
45
8
2
R7048
3
5
USB
TO
F-SW
BOARD
CN901
A
TO
S-SW
BOARD
CN902
B
TO
LCD
MIC2
Lch
MIC1
ZOOM
MIC3
Rch
R7047
(Page 18) (Page 19)
