Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
39
ICD-ST25
MAIN S-SW
R6018 1-218-977-11 RES-CHIP 100K 5% 1/16W
R6019 1-218-977-11 RES-CHIP 100K 5% 1/16W
R6020 1-218-977-11 RES-CHIP 100K 5% 1/16W
R6021 1-218-977-11 RES-CHIP 100K 5% 1/16W
R6022 1-218-937-11 RES-CHIP 47 5% 1/16W
R6025 1-218-949-11 RES-CHIP 470 5% 1/16W
R6026 1-218-977-11 RES-CHIP 100K 5% 1/16W
R6027 1-218-977-11 RES-CHIP 100K 5% 1/16W
R7001 1-218-989-11 RES-CHIP 1M 5% 1/16W
R7002 1-218-941-11 RES-CHIP 100 5% 1/16W
R7003 1-218-941-11 RES-CHIP 100 5% 1/16W
R7006 1-208-691-11 METAL CHIP 2.2K 0.5% 1/16W
R7007 1-208-683-11 METAL CHIP 1K 0.5% 1/16W
R7008 1-208-683-11 METAL CHIP 1K 0.5% 1/16W
R7009 1-218-989-11 RES-CHIP 1M 5% 1/16W
R7010 1-218-965-11 RES-CHIP 10K 5% 1/16W
R7011 1-218-985-11 RES-CHIP 470K 5% 1/16W
R7012 1-218-985-11 RES-CHIP 470K 5% 1/16W
R7013 1-208-707-11 METAL CHIP 10K 0.5% 1/16W
R7014 1-208-707-11 METAL CHIP 10K 0.5% 1/16W
R7015 1-218-953-11 RES-CHIP 1K 5% 1/16W
R7016 1-218-981-11 RES-CHIP 220K 5% 1/16W
R7019 1-218-990-11 SHORT CHIP 0
R7020 1-218-953-11 RES-CHIP 1K 5% 1/16W
R7022 1-218-953-11 RES-CHIP 1K 5% 1/16W
R7023 1-218-985-11 RES-CHIP 470K 5% 1/16W
R7025 1-218-985-11 RES-CHIP 470K 5% 1/16W
R7027 1-218-977-11 RES-CHIP 100K 5% 1/16W
R7028 1-218-990-11 SHORT CHIP 0
R7029 1-218-977-11 RES-CHIP 100K 5% 1/16W
R7030 1-218-941-11 RES-CHIP 100 5% 1/16W
R7031 1-218-977-11 RES-CHIP 100K 5% 1/16W
R7032 1-218-977-11 RES-CHIP 100K 5% 1/16W
R7033 1-218-977-11 RES-CHIP 100K 5% 1/16W
R7034 1-218-977-11 RES-CHIP 100K 5% 1/16W
R7038 1-218-977-11 RES-CHIP 100K 5% 1/16W
R7039 1-218-953-11 RES-CHIP 1K 5% 1/16W
R7040 1-218-985-11 RES-CHIP 470K 5% 1/16W
R7043 1-218-985-11 RES-CHIP 470K 5% 1/16W
R7044 1-218-953-11 RES-CHIP 1K 5% 1/16W
R7045 1-218-977-11 RES-CHIP 100K 5% 1/16W
R7046 1-218-977-11 RES-CHIP 100K 5% 1/16W
R7047 1-218-953-11 RES-CHIP 1K 5% 1/16W
R7048 1-218-953-11 RES-CHIP 1K 5% 1/16W
R7049 1-218-990-11 SHORT CHIP 0
R7050 1-218-953-11 RES-CHIP 1K 5% 1/16W
R8001 1-218-985-11 RES-CHIP 470K 5% 1/16W
R8002 1-218-985-11 RES-CHIP 470K 5% 1/16W
R8003 1-218-977-11 RES-CHIP 100K 5% 1/16W
R8004 1-218-977-11 RES-CHIP 100K 5% 1/16W
R8005 1-218-985-11 RES-CHIP 470K 5% 1/16W
R8006 1-218-989-11 RES-CHIP 1M 5% 1/16W
R8007 1-218-985-11 RES-CHIP 470K 5% 1/16W
R8009 1-218-945-11 RES-CHIP 220 5% 1/16W
R8010 1-218-977-11 RES-CHIP 100K 5% 1/16W
R8011 1-218-977-11 RES-CHIP 100K 5% 1/16W
R8012 1-218-977-11 RES-CHIP 100K 5% 1/16W
R8013 1-218-957-11 RES-CHIP 2.2K 5% 1/16W
R8015 1-218-933-11 RES-CHIP 22 5% 1/16W
R8016 1-218-933-11 RES-CHIP 22 5% 1/16W
R8020 1-242-967-11 RES-CHIP 1 5% 1/16W
R8021 1-218-961-11 RES-CHIP 4.7K 5% 1/16W
R8022 1-218-949-11 RES-CHIP 470 5% 1/16W
< COMPOSITION CIRCUIT BLOCK >
RB6001 1-233-973-11 RES, NETWORK (CHIP TYPE) 100K
RB6002 1-233-973-11 RES, NETWORK (CHIP TYPE) 100K
< SWITCH >
S7001 1-572-922-11 SWITCH, SLIDE (HOLD)
< TRANSFORMER >
T5001 1-416-405-11 FILTER, CHIP EMI (COMMON MODE)
< THERMISTOR >
TH5001 1-805-202-11 THERMISTOR, POSITIVE
< VARISTOR >
VDR50021-805-216-21 VARISTOR, CHIP
< VIBRATOR >
X6001 1-795-758-21 VIBRATOR, CRYSTAL 11.2896MHz
X7001 1-795-116-11 VIBRATOR, CERAMIC 4.096MHz
X8001 1-795-752-21 VIBRATOR, CRYSTAL 12MHz
************************************************************
* A-4547-170-A S-SW BOARD, COMPLETE
*********************
3-250-050-21 BUTTON (5D)
< CAPACITOR >
C901 1-164-941-11 CERAMIC CHIP 0.0047uF 10% 16V
C902 1-164-941-11 CERAMIC CHIP 0.0047uF 10% 16V
< CONNECTOR >
* CN902 1-815-284-11 CONNECTOR, FPC (ZIF) 8P
< RESISTOR >
R905 1-208-691-11 METAL CHIP 2.2K 0.5% 1/16W
R906 1-208-695-11 METAL CHIP 3.3K 0.5% 1/16W
R907 1-208-699-11 METAL CHIP 4.7K 0.5% 1/16W
R908 1-208-715-11 METAL CHIP 22K 0.5% 1/16W
R909 1-208-715-11 METAL CHIP 22K 0.5% 1/16W
R910 1-208-719-11 METAL CHIP 33K 0.5% 1/16W
R911 1-208-719-11 METAL CHIP 33K 0.5% 1/16W
< SWITCH >
S906 1-771-844-11 SWITCH, TACTILE (SMD) (VOL-)
S907 1-771-844-11 SWITCH, TACTILE (SMD) (VOL+)
S908 1-771-844-11 SWITCH, TACTILE (SMD) (x STOP)
S909 1-771-844-11 SWITCH, TACTILE (SMD) (z REC/REC PAUSE)
S910 1-786-294-51 SWITCH, MULTIPLE FUNCTION
(PUSH V PLAY/STOP(ENTER))
************************************************************
