ICF-CDK70
14
– TU BOARD (Component Side) –
– TU BOARD (Conductor Side) –
L4
AM VCO Voltage Adjustment
L2
FM VCO Voltage Adjustment
FM Tracking Adjustment
T1 AM IF Adjustment
T2 FM IF Adjustment
L1
CT1
AM Tracking Adjustment
L3
CT3
TP (VT)
TP (GND)
TP (ANT)
Adjustment Location:
