ICF-CDK70
34
Pin No. Pin Name I/O Description
63, 64 SEG0, SEG1 O Segment drive signal output to the liquid crystal display
65 VCC - Power supply terminal (+3.3V)
66 VSS - Ground terminal
67 to 81 SEG2 to SEG16 O Segment drive signal output to the liquid crystal display
82 to 84 NC O Not used
85 O-TIMER LED O LED drive signal output terminal
86, 87
I-ENCODER-TIMER+,
I-ENCODER-TIMER-
I Jog dial pulse input from the rotary encoder (TIMER)
88, 89 NC O Not used
90 VCC - Power supply terminal (+3.3V)
91 VSS - Ground terminal
92 X1 O Main system clock output terminal (4.19 MHz)
93 X0 I Main system clock input terminal (4.19 MHz)
94 O-CLK-SHIFT AM O Oscillation frequency selection on/off control signal output terminal for AM "H": selection on
95 O-CLK-SHIFT FM O Oscillation frequency selection on/off control signal output terminal for FM "H": selection on
96 O-POWER AUDIO IN O Not used
97 O-POWER TUNER O Tuner power on/off control signal output terminal "H": power on
98 O-TU-MUTE O Tuner muting on/off control signal output to the FM/AM PLL "H": muting on
99 I-TU-DI I Serial data input to the FM/AM PLL
100 O-TU-CLK O Serial data transfer clock signal output to the FM/AM PLL
