Using the SNC toolbox
5
Device list
Devices registered in the folder selected at Device tree
view are displayed in a list.
Device name
Displays individual device names.
Status (Only for Error folder and My device
folder)
You can check the current connection status.
MAC address
You can check the MAC address of the device.
Device address
You can check the IP address of the device.
Port No., HTTP Port No.
You can check the port number of the device.
DHCP/Fixed IP
Displays whether the IP address of the selected device is
DHCP or fixed IP.
Client certificate
Displays the name of the client certificate used for SSL
function.
Model
Displays the model name.
Serial No.
Displays the serial number.
Version No.
Displays the version of firmware.
Admin name
Displays the administrator user name.
IP Address of NIC (Search result folder only)
Displays the IP address of the NIC (Network Interface
Card) detected.
Tips
• A camera with which SSL communication has been
performed will show on the left side of its IP
address.
• The model on sale in China does not support the SSL
function.
View button
You can change the display format of the Device list
(page 9) .
Searching devices
Clicking Search enables you to detect network devices
connected to the network. In the initial status, it detects
devices on the same network segment. However after
configuring search settings, it is able to search devices
even outside the network segments.
For details on Search settings, see “Setting SNC toolbox
options – Network tab – Search Setting” (page 11).
SNC toolbox automatically searches devices on a
regular basis. You can determine the status of the search
function from the Search button.
Searching
Searches devices on the network on a regular basis and
updates the device list automatically. Click to stop
searching.
Stop Searching
Searching stopped. Click to resume searching.
To expand search range
Configure the search settings.
1
Click Option under To ol s.
2
Click the Network tab.
3
Place a check on Search external network
device(s) in Search Setting.
To search in a wider range, set the greater value in TTL.
Tip
If the device is not detected even with the correct search
settings, see “Note” in “Setting SNC toolbox options –
Network tab – Search Setting” (page 11).
Assigning an IP address
To connect the device via network, you need to assign a
new IP address to the device when you install it for the
first time.
Clicking Network after selecting a device to configure
network settings with from the device list, the Network
setting dialog will be displayed. This dialog is
configured with two types of tabs, Basic Setting and
IPv6 Setting.
