Sony KF-42E200A - Page 112

A-2
KF-42E200A/42E201A/50E200A/50E201A
KF-42E200A/42E201A/50E200A/50E201A
4 Remove the outside lamp cover.
5 Remove the lamp door.
Turn the knob counterclockwise to OPEN and pull out
the cover.
6 Pull out the lamp.
Hook a finger through the loop of the lamp handle and
pull the handle upwards. Then pull the lamp straight out.
7 Put the new lamp into its place.
Mount the new lamp securely. Failure to do so may cause
a fire or the screen to go dark.
✍ The lamp is very hot immediately after use.
Never touch the glass portion of the lamp or the
surrounding parts.
✍ After the used lamp has cooled, place it into the
empty box of the replacement lamp. Never put
the used lamp into a plastic bag.
✍ If the lamp is not securely reattached, the self-
diagnostic function may be triggered and the
POWER indicator flashes three times (see page
11).
Lamp door
(Continued)
