KF-42E200A/42E201A/50E200A/50E201A
KF-42E200A/42E201A/50E200A/50E201A
29
x Secure Ring Terminal of 1-910-016-90 to G-Block as shown above.
x Install Faston Terminal to Antenna Switch.
Note: Orientation of ring terminal should be towards the top of the set.
1-910-016-90
OPTICAL BLOCK ASSEMBLY LIGHTNING GROUND POSITION
